- Elica aluminum mesh filters are a step above competition, featuring triple layered, anodized aluminum that is woven into a highly dense mesh. The thick mesh captures more grease, anodization helps resist staining and provides durability to repeated cleanings in the dishwasher.
- LED lighting is undoubtedly the smartest solution in terms of energy saving. Expected life time of over 20.000 hours, represents the most remarkable advantage of LED light bulbs.
Manufacturer's Warranty: 2 years
UPC: 190603001877
UPC: 190603001877
EAN: 0190603001877
Warranty | 3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com |
SHIPPING WEIGHT (kg) | 8.60 |
NET WEIGHT (kg) | 7.60 |
CARTON LENGHT (mm) | 173.00 |
CARTON HEIGHT (mm) | 536.00 |
CARTON WIDTH (mm) | 803.00 |
VOLUMEN (M3) | 0.10 |
SHIPPING WEIGHT | 18.96 |
NET WEIGHT | 16.76 |
CARTON LENGHT | 6.81 |
CARTON HEIGHT | 21.10 |
CARTON WIDTH | 31.61 |
COUNTRY OF MANUFACTURE | MX |
QTY PACKAGE | 1.00 |
INTENDED APPROVED USE | Residential use |
Finish | Stainless Steel |
Color | inox |
Type of Ventilation | Convertible |
HOODS FEATURES | 3x layer mesh,Led light |
WIDTH (IN) | 30" |
WIDTH (CM) | 76.00 |
AIRFLOW (M3/H) | 475.00 |
CFM (MAX) | 280.00 |
db (min) | 32.00 |
db (max) | 51.00 |
SONES | 1.3 - 4.9 |
EXHAUST VERSION | Convertible with Kit |
EXHAUST SIZE | Rectangular 10 x 3 1/4" or round 7" (sold separately) |
DUCT SHAPE | Rectangular or round (sold separately) |
EXHAUST LOCATION | Top or Rear |
RECTANGULAR DUCTH HEIGHT | 10" |
RECTANGULAR DUCT WIDTH | 3.25 |
Round duct diameter | 7" |
ELECTRIC (VOLTS) | 120 V/60 Hz |
AMPERAGE | 1.0 A |
HERTZ | 60.00 |
WATTS | 115.00 |
LIGHTING | LED 2 x 2.1 ww 4000 KK |
BULB TYPE | LED |
BULB INCLUDED | YES |
NUMBER OF LIGHTS | 2.00 |
BULB WATTS | 2.10 |
KELVINS | 4000.00 |
GREASE FILTER TYPE | Dishwasher-Safe, Anodized Aluminum Mesh Filter |
DISHWASHERSAFE FILTER | YES |
FILTER MATERIAL | Aluminum Mesh |
BLOWER TYPE | Interior Unit |
CONTROL TYPE | Backlit Electronic Push Button |
SPEED CONTROL | YES |
NUMBER OF SPEEDS | 3.00 |
REMOTE CONTROL | NO |
POWER SOURCE | Hardwired |
OUTDOOR USE | NO |
SMUDGE RESISTANT | NO |
RECIRCULATION KIT NEEDED | YES |
CFM REDUCTION | NA |
DIMENSIONS | 76 x 47 x 12.5 |
DIMENSIONSinches | 30" x 18 5/8" x 5" |
ADJUSTABLE HEIGHT | NO |
Minimum Overall Height - Top to Bottom | 5" |
Maximum Overall Height - Top to Bottom | 4 5/16 |
Overall Height - Top to Bottom | 4 5/16 |
Overall Width - Side to Side2 | 30" |
Overall Depth - Front to Back | 18 5/8" |
Hood Height | 5" |
Minimum Compatible Ceiling Height | NA |
Maximum Compatible Ceiling Height | NA |
Minimum Height Above Cooktop (ELECTRIC) | = 24 |
Minimum Height Above Cooktop (GAS) | = 30 |
Maximum Height Above Cooktop | 36" |
Chimney Width - Side to Side | NA |
Chimney Depth - Front to Back | NA |
Chimney Height - Top to Bottom | NA |
RECIRCULATION KIT NUMBER | KIT02179 |
CHIMNEY EXTENSION NUMBER | NA |
TELESCOPIC DUCT COVER | - |
DUCT TRANSITION | KIT02722 |
TRANSITION REDUCER KIT | - |
BACKDRAFT DAMPER | KIT02723 |
NON RETURN VALVE | - |
UPGRADE FILTER | - |
CFM REDUCTION KIT | - |
BACKSPLASH KIT | - |
INTERNAL BLOWER | - |
INLINE BLOWER | - |
EXTERNAL BLOWER | - |
INLINE BLOWER SHELL KIT | - |
EXTERNAL BLOWER SHELL KIT | - |
HEAT LAMPS | - |
SPACER/LINER | - |
WALL MOUNT BRACKET | - |
HIGH CEILING EXTENSION KIT | - |
REMOTE CONTROL KIT | - |
cUL listed | YES |
UL listed | YES |
AHAM verified | YES |
TITLE 24 | YES |
Prop65Disclosure | YES |
ENERGY STAR | NO |
WIFI CAPABLE | NO |
COMERCIAL USE APPROVED | NO |
ADA COMPLIANT | NO |
APP CAPABLE | NO |
VENTILATION DIRECTION | HORIZONTAL |
SMART COMPATIBLE | NO |
FITLER INDICATOR LIGHT | NO |
HEAT SENSOR | NO |
CHAROCAL FILTER | YES |
CERTIFICADO NOM | NA |
Selected Model | |
Color | Stainless Steel |
Model number | ENM230S1 |
Dimensions | |
Dimensions | 30'' (W) X 18¾'' (D) X 5'' (H) |
Exterior Appearence | |
Stainless Steel grade | 430 |
Features | |
Controls | Soft Touch, illuminated |
Illumination | 2, 2.1W LED light, 1 intensity (bulbs included) |
Blower Type | 280 CFM, 3- Speed |
Blower Performance | Speed 1, 110 CFM, 1.5 Sones Speed 2, 200 CFM, 3.2 Sones Speed 3, 280 CFM, 4.7 Sones |
Filter Type | Dishwasher-Safe, Anodized Aluminium Mesh |
Ducting | Ducted or Recirculating Installation (Recirculating Kit Sold Separately) |
Duct transition | 3¼’’ X 10’’ (Top or Rear) |
Electrical Requirements | |
Electrical requirements | 120V / 60Hz / 115 Watt / 1 Amps |
Accessories (optionnal) | |
Recirculating Kit | KIT0140997 |
7'' round duct transition (top) | KIT0142872 Duct transition- 7'' round KIT02723 Back Draft Damper included |
Warranty | |
Complete 2 years warranty | Entire Appliance; In-Home; Parts & Labour |
