Top 3 Features
7-Inch Full Color LCD Display
Visually vibrant. This highly-interactive, full-color display is packed with dynamic features that allow you to navigate effortlessly through settings and the JennAir® Culinary Center.
Cinematic Lighting
Lights, camera, cook. Halogen lighting increases to full intensity, minimizing shadows and dramatically showcasing food.
Seamless Touches
Seamlessly designed. Concealed details melt into their stainless steel surround, as dark interiors and glass expanses pull you in.
Additional Features
Glide Rack
Smooth moves. Glides in and out fluidly and quietly, even when fully loaded.
Irresistible Interior
Captivation cloaked in black. Beyond a dark glass expanse, cinematic lighting illuminates smooth racks, flat tines, and an enticing jet black interior.
Chef's Light
Food shown in its best light. This third halogen lamp shines above the door, front and center, further reducing shadows for clear illumination.
5.0 Cu. Ft. Capacity
Big on entertaining. Generous capacity to cook multiple dishes at once.
Smooth Close Door
Quiet, soft, secure. Your oven gently pulls the door closed.
Closed Door Broiling
Turn up the heat behind closed doors. Caramelized crust. Delicate char. Tender center. High, even heat means you can sear fearlessly.
V2™ Vertical Dual-Fan Convection
Dual counter-rotating vertical fans work in tandem, helping you wield your cooking prowess with everything from mouthwatering fillets to irresistible roasts.
Versatile Cooking Modes
Uncompromising results, untroubled process. Automatically convection cook by food type, or manually select convection modes by cooking method. Take the guesswork out of convection cooking with automatic temperature and time conversions. Get even more vers
JennAir® Culinary Center
With step-by-step support, savor the full culinary experience backed by customized algorithms, featuring full-color food photography, doneness levels, pan types and menu-specific tips.
My Creations
Curate recipe presets at will. Bake for 30 minutes, broil for 4 and keep dishes warm until you're ready to dine—all without lifting a finger.
No Preheat Baking
Bake on a single rack without the wait.
2,800-Watt Hidden Bake Element
Unleash hidden power. This 2,800-watt bake element is concealed beneath the oven floor, providing even heat and a smooth surface that is easy to clean.
4,000-Watt Broil Element
Tap into high-watt, even heat designed to broil meats with this 4,000-watt element for savory, caramelized crust.
Control Lock
Control Lock prevents unintended use of the oven and ensures complete, simple cleaning of the controls.
Convection Tower
A touch of style in an unexpected place. Dual vertical fans work in tandem, helping you wield your cooking prowess with everything from mouthwatering fillets to irresistible roasts.
8-Pass Reflective Broil Element
Maximum coverage. Even heat distribution. Beneath a stainless steel broil plate, this element radiates heat back onto cookware and food.
6,800-Watt Combined Convection Capacity
Uncompromising prowess.Two 3,400-watt convection elements combine to create powerful, even heat for dishes that make an impact.
3,400-Watt Convection Element
Power, controlled. Evenly bake breads and cook main dishes in a controlled environment powered by this 3,400-watt convection element.
Auto Convection Conversion
Bake with abandon. The oven automatically converts temperature and cook time to make any recipe a convection recipe.
Auto Convection Modes
Savour taste that leaves you wanting more. Choose your food type, and temperature and airflow automatically adjust for baking, broiling or roasting.
Manual Convection Modes
Select from presets like Convect Bake, Convect Roast and Convect Broil to let the cooking method guide you.
Rapid Preheat
Reduce preheat time in the lower oven while baking on up to two oven racks.
Proofing Option
Tame the temperamental. Low, consistent heat protects dough from temperature swings for an even, rapid rise.
Keep Warm™ Option
Reward anticipation. Low heat keeps tempting dishes ready and waiting for the right moment.
Sabbath Mode
Select this function to bypass the oven’s automatic shutoff when observing the Sabbath and other religious holidays.
Remote Access
Preheat. Check cooking status. Personalize settings. Connect to WiFi for real-time notifications and control your appliance from anywhere. Tap and swipe on both iOS and Android devices.**Appliance must be set to remote enable. WiFi & App required. Feature
On-Demand Experts
Connect with the JennAir Epicenter through chat, email, or call to tap into the brilliant minds of experts who know JennAir® appliances inside and out. Receive diagnostic codes on the app and they'll deploy service targeted to your wall oven's best intere
Experts at the Ready
Our crew relentlessly engages with JennAir® appliances day in, day out. Initiated in rigorous product, process and culinary training, this team answers to you—from sales to installation to ownership.
Smart Integration (U.S. Only)
Use voice commands with the Google Assistant. Not Available in Canada.
Serviced by a Select Few
We narrowed down our dedicated network to only the most experienced providers. Armed with extensive access to products and knowledge, their expertise is unmatched.
Cook on Command (U.S. Only)
Not Available in Canada
Connected Temperature Probe
Know when dinner is done without ever opening the door. Readings of food’s internal temperature, visible on the LCD screen or directly from the app.* *Appliance must be set to remote enable. WiFi & App required. Features subject to change. For details and
Alexa Enabled Device (U.S. Only)
Not Available in Canada
Google Assistant Enabled Device (U.S. Only)
Not Available in Canada
Manufacturer's Warranty: 2 years
Canadian model: JJW3430IL
Canadian UPC: 883049516042
EAN: 0883049516042
| Dimensions | |
| Capacity | 5.00 |
| Depth | 23-1/4 in |
| Height | 29-7/8 in |
| Net Weight | 158 lbs |
| Width | 30.0 in |
| Configuration and Overview | |
| Fuel Type | Electric |
| Installable Under Cooktop | Yes |
| LP Convertible | No |
| Oven Type | Single |
| Size | 30 in |
| Oven Details | |
| Automatic Shut-Off | Yes |
| Broiler Location | Top of Oven |
| Convection Functions | Bake Broil Roast Upper |
| Delay Clean | Yes |
| Door Broil Position | Closed |
| Door Lock | Yes |
| Hidden Bake Element | Yes |
| Interior Coating | Porcelain |
| Interior Color | Black |
| Language Conversion | English/French |
| Light Control | Oven Light Touch Pad |
| Light Type | Halogen |
| Number of Bake Elements | 1 |
| Number of Broil Elements | 1 |
| Oven Interior Depth | 19.0 in |
| Oven Interior Height | 18.0 in |
| Oven Interior Width | 25.0 in |
| Power On Indicator Light | Yes |
| Self-Cleaning Oven Racks | No |
| Appearance | |
| Flush Installation Approved | Yes |
| Handle Material | Stainless Steel |
| Certifications | |
| Kosher Consumer Friendly | Yes |
| Prop 65 | CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov . |
| UL | Yes |
| Electrical | |
| Power Cord Included | No |
| Watts | 4500 |
| Compatibility | |
| Connectivity | Amazon Alexa, Android, Google Assistant, iOS, Nest, Siri |
| Works With | WiFi, App, Remote Access, Voice Controlled |
| Design Type | |
| Design Expression | RISE™ |
| Details | |
| Number of Oven Racks | 3 |
| Number of Rack Guides | 6 |
| Description | |
| Cooktop Combinations | JEC3430, JEC3536, JEC4424, JEC4430, JEC4536, JIC4430, JIC4536, JIE4115GS, JIC4715GS, JGC1530, JGC1536, JGC2530, JGC2536, JGC7530, JGC7636, JGC3115G, JGC3530, JGC3536, JIC4324, WCG52424 |
| Fuel Type | Electric |
| Dimensions | |
|---|---|
| Depth | 23 1/4 |
| Width | 30 |
| Height | 29 7/8 |
| Carton Depth | 31 5/16 |
| Carton Height | 30 7/8 |
| Carton Width | 35 1/4 |
| Cutout Depth | 24 |
| Cutout Height | 29 7/16 |
| Cutout Width | 28 1/2 |
| Depth Closed Excluding Handles | 24 5/16 |
| Depth Closed Including Handles | 27 1/8 |
| Depth Excluding Doors | 23 |
| Depth With Door Open 90 Degree | 45 7/16 |
| Gross Weight | 175 |
| Net Weight | 158.2 |
| Capacity (cubic feet) | 5.00 |
| Certifications | |
| Prop 65 | Standard |
| ADA Compliant | ADA Height and Side and Front Reach Compliant |
| CUL | Yes |
| UL | UL |
| Energy Rating (kWH/year) | 407 |
| Kosher Consumer Friendly | Yes |
| Configuration and Overview | |
| Oven Type | Single |
| Fuel Type | Electric |
| Size (IN,inches) | 30 |
| Installable Under Cooktop | Yes |
| LP Convertible | No |
| Controls | |
| Control Type | Tap Touch |
| Electronic Display Type | LCD Screen |
| Description | |
| Cooktop Combinations | JEC3430,JEC3536,JEC4424,JEC4430,JEC4536,JGC1530,JGC1536,JGC2530,JGC2536,JGC7530,JGC7636,JIC4430,JIC4536,JIC4715GS,JIE4115GS |
| Oven Details | |
| Door Lock | Yes |
| Language Conversion | English/French |
| Automatic Shut-Off | Yes |
| Power On Indicator Light | Yes |
| Interior Color | Black |
| Number of Bake Elements | 1 |
| Oven Cooking System | Convection |
| Door Broil Position | Closed |
| Number of Broil Elements | 1 |
| Hidden Bake Element | Yes |
| Broiler Location | Top of Oven |
| Interior Coating | Porcelain |
| Convection Functions | Bake Broil Roast Upper |
| Light Control | Oven Light Touch Pad |
| Light Type | Halogen |
| Delay Clean | Yes |
| Self-Cleaning Oven Racks | No |
| Exterior | |
| Oven Door | Metal & Glass |
| Handle Color | Stainless Steel |
| Appearance | |
| Handle Material | Stainless Steel |
| Flush Installation Approved | Yes |
| Features | |
| Selection | Audible Signal,Control Lock,Cancel/Off,Slow Cook,Cook and Hold,Language Conversion,Temperature Conversion,Favorites,Start Time,Stop Time,Bake,Temperature-Sensor Baking,Broil,Proofing,Cook Time Indicator,Delay Start,Warm Hold,Sabbath Mode,Rapid Preheat,Clock,Temperature Probe,Timer |
| Details | |
| Bake Element Power | 2800W/2427W |
| Broiler Element Power | 4000W |
| Convection Element Power (watts) | 6800 |
| Convection Element Type | Dual-Fan |
| Number of Oven Lights | 3 |
| Oven Rack 1 Type | Standard |
| Number of Rack Guides | 6 |
| Oven Rack 2 Type | Gliding Roll-Out |
| Oven Interior Depth(IN,inches) | 19 |
| Oven Cleaning Type | Self-Cleaning |
| Number of Oven Racks | 3 |
| Oven Interior Width(IN,inches) | 25 |
| Oven Interior Height(IN,inches) | 18 |
| Electrical | |
| Power Cord Included | No |
| Amps | 20 |
| Watts | 4500 |
| Hz | 60 |
| Volts | 240/208 |
| Refinement | |
| Style | Wall Ovens |
| Configuration | |
| Oven Configuration | Single Oven |
| Design Type | |
| Design Expression | RISE™ |
| Compatibility | |
| Connectivity | Amazon Alexa,Android,Google Assistant,iOS |
| Works With | WiFi,App,Remote Access,Voice Controlled |
Warranty (JJW3430IL-warranty-canada.pdf)
