30" Masterpiece® Series Gas Cooktop SGSX305FS
It's the most powerful 30-inch gas cooktop in the luxury segment. Our fourth generation Star® Burner puts more heat on the pan for faster cooking, and our exclusive ExtraLow® burners give the lowest temperature simmer available
- Innovation
- Most powerful 30" cooktop in the luxury segment (amongst leading manufacturers) with an overall output of 52,000 BTU
- Patented and exclusive Star Burner provides superior performance
- Exclusive 200 BTU ExtraLow burners for perfect simmering
- Progressive illuminated control panel with metal knobs
- Performance
- 30" - 5 burner gas cooktop provides functionality of a 36" cooktop in a compact kitchen environment
- Powerful 16,000 BTU Center Burner
- Continuous grates allow pots and pans to glide smoothly across the cooktop
- Automatic electronic re-ignition
- Knobs feature a safety "push to turn" system
- Single point ignition - only burner that is being used is ignited
- Design
- Chiseled, angular design coordinates with the suite of Thermador Masterpiece Collection appliances
- High-grade, quality die cast metal knobs
- Sleek control panel features glass and stainless steel
Manufacturer's Warranty: 2 years
Canadian model: SGSX305FS
Canadian UPC: 825225853312
EAN: 0825225853312
| Technical Specifications | |
| Energy source | Gas |
| Type of control | sword knobs |
| Safety device | automatic reignition |
| Construction type | |
| Color of frame | Stainless steel |
| Color of surface | Stainless steel |
| Installation type | Built-in |
| Number of electric elements | 0 |
| Number of electric cooking zones | 0 |
| Number of gas burners | 5 |
| Number of halogen elements | 0 |
| Installation Type | Built-in |
| Type of grate | Cast iron |
| Total number of cooktop burners | 5 |
| Number of radiant elements | 0 |
| Number of electric warming zones | 0 |
| Size and weight | |
| Overall appliance dimensions (HxWxD) (in) | + 3 13/16'' x 31'' x 21 1/4'' |
| Net weight (lbs) | 42 lbs |
| Cooking zone 1 | |
| Location of 1st heating element | front left |
| Cooking zone 2 | |
| Location of 2nd heating element | center left |
| Cooking zone 3 | |
| Location of 3rd heating element | back left |
| Cooking zone 4 | |
| Location of 4th heating element | middle back |
| Cooking zone 5 | |
| Location of 5th heating element | back right |
| Cooking zone 6 | |
| Location of 6th heating element | center right |
| Cooking zone 7 | |
| Location of 7th heating element | front right |
| Cooking zone 8 | |
| Location of 8th heating element | front middle / central |
| Cooking zone 9 | |
| Location of 9th heating element | front centre/cent |
| Safety | |
| Type of safety device for gas | Without |
| Residual heat indicator | without |
| Safety device | automatic reignition |
| Connection | |
| Gas connection rating (W) | 15,240 W |
| Location of gas connection | bottom, rear, right |
| Frequency (Hz) | 60 Hz |
| Energy source | Gas |
| Watts (W) | 1,800 W |
| Power Cord Length | 60'' |
| Accessories | |
| Included accessories | 3 x cast iron pan support |
Product Specs (SGSX305FS-product-specs-canada.pdf)
