Whirlpool

UVL6048JSS

• KitchenAid® Custom Hood Liners design – allows the ventilation system to be concealed inside custom cabinetry or a decorative hood cover for a seamless, built‑in look that matches your kitchen style.

• 105,000 BTU rating – pairs with KitchenAid® commercial‑style ranges, rangetops and other high‑output cooking appliances up to 105,000 BTU, helping to clear heavy smoke and steam from powerful burners.

• Requires 585 or 1170 CFM Motor Class blower (sold separately) – lets you choose between two commercial‑style blower options to match your cooking style and local ventilation requirements.

• Three‑speed fan – offers low, medium and high settings so you can tailor ventilation power from gentle simmering to intense searing.

• 3‑speed hidden slide control – discreet slide controls are tucked away for a clean, uncluttered appearance while still being easy to reach and adjust.

• 585–1170 CFM Motor Class performance – supports powerful airflow (depending on blower chosen) to quickly remove smoke, grease and odors from larger cooktops and ranges.

• Four LED task lights – bright, natural‑looking LED lighting clearly illuminates the entire cooking surface for better visibility while preparing meals.

• Night light setting – offers a softer illumination option to create an inviting ambient glow in the kitchen during evenings or overnight.

• Aluminum mesh / grease filters – multi‑layer filters help capture grease, steam and cooking odors to keep the air cleaner and protect the blower and ductwork.

• Removable, washable filters – filters can be easily removed and cleaned with soap and water, reducing replacement costs and helping maintain peak performance.

• Under‑cabinet / insert hood liner configuration – designed to be installed inside a custom enclosure (metal, wood, plaster or tile), ideal for premium, built‑in kitchen designs.

• Exterior venting system – vents air to the outside of the home, helping to remove heat, moisture and odors rather than recirculating them back into the kitchen.

• Vertical round ducting – uses a 10" round vertical duct outlet to support high airflow and efficient exhaust routing through the ceiling or upper cabinetry.

• Integrated damper included – helps prevent backdrafts and outside air from entering the home when the hood is not in use.

• Centrifugal blower design (with compatible motors) – supports strong, consistent airflow and efficient removal of smoke and grease when paired with the appropriate blower.

• Large 48" width – sized to cover wider cooking surfaces and 48" ranges, improving capture of smoke and steam across the full cooktop.

• Deep 22" canopy – extended depth helps capture rising smoke and steam more effectively, especially from front burners and large cookware.

• Hidden control location – keeps controls out of direct sightlines for a streamlined, professional appearance under custom hoods.

• Stainless steel construction – durable, corrosion‑resistant finish stands up to daily cooking and wipes clean easily for low‑maintenance care.

• LED task lighting with slider control – slider‑style lighting control lets you quickly adjust brightness to suit cooking or ambient needs.

• Designed for larger cooking appliances – engineered to work with high‑capacity ranges and rangetops, making it suitable for serious home cooks and frequent entertainers.

• Supports high BTU threshold (65K/105K) – accommodates both standard high‑output and commercial‑style burner configurations without compromising ventilation performance.

• Top exhaust vent location – simplifies duct routing straight up through cabinetry or the ceiling in many standard kitchen layouts.

• Exterior‑only venting (no recirculating kit) – ensures that smoke, grease and odors are exhausted outdoors for better overall indoor air quality.

• Standard 120V, 60 Hz electrical connection – connects to typical North American household power, simplifying installation by a qualified installer.

• Non‑Energy Star design – prioritizes high airflow and performance for demanding cooking environments over Energy Star certification.

• Compatible with multiple blower kits – flexibility to upgrade or choose the blower that best fits your kitchen size, duct run and local code requirements.

• Professional‑style look when paired with custom hood – delivers a high‑end, built‑in aesthetic comparable to commercial‑style kitchens.

• Helps protect kitchen surfaces – effective capture of grease and steam reduces residue buildup on cabinets, walls and ceilings around the cooking area.

• Improves comfort while cooking – removes excess heat and humidity from the cooktop area, helping keep the kitchen more comfortable during long cooking sessions.
