Installing this stove hood is quick and easy. The FIT system eliminates measuring, cutting and filler strips for a smooth fit every time. Once installed, the hood vent kitchen fan operates at a quiet 58 dBA (3.0 sones) at working speed so it won't disturb family time in the kitchen. Plus, incandescent lighting helps you keep a close eye on food so each dish turns out the way you want it to. And when cooking introduces steam, grease, smoke or odors into the surrounding air, a 225 CFM motor class takes care of it.
- FIT System
- The FIT system eliminates measuring, cutting and trim for a perfect fit every time.
- 58 dBA (3.0 sones) at Low Speed
- Keep noise down in the kitchen with the quiet operation of 68 dBA (6.4 sones) at the hood's highest speed with a recirculation option.
- Hidden Vent
- Powerful Variable-Speed, 225 CFM Motor Class
- Variable speeds provide the right amount of ventilation for every meal you prepare.
- Incandescent Lighting
- Incandescent lighting makes it easy to see what you're cooking with bulbs that are inexpensive to replace.
- 3-1/4" x 10" Damper
One person. No measuring. Easy install.
Time consuming ways of installing hoods are now a thing of the past. The FIT system provides fast installation thats simple enough for one person.
FIT System
The FIT system eliminates measuring, cutting and filler strips for a perfect fit every time. The FIT system ensures your hood will install seamlessly into your cabinet cutout in three easy steps. First, attach FIT brackets and prep hood for electrical connection; second, position hood and attach to cabinet; third, complete electrical connection to hood. Now the only thing left to do is use it. Based on typical installation with existing electrical and ventilation connections. Consult a professional installer to ensure your installation complies with code requirements.
Deluxe Hood Sound Levels
Keep the hood from disturbing family time in the kitchen. This hood features the quiet operation of 6.4 sones at the hood's highest speed with variable fan speeds and a recirculation option. Based on vertical 7" round duct installation.
Hidden Vent
This sleek and stylish hidden vent matches almost every modern or traditional kitchen. The design moves the ventilation out of sight to create a seamless look and a surface that's super easy to clean.
Powerful Variable-Speed, 225 CFM Fan
Cooking introduces steam, grease, smoke and odors into the surrounding air. With a powerful variable speed 225 CFM fan, this hood is a perfect match for a midsize cooktop and some high-heat cooking methods.
Incandescent Lighting
Incandescent bulbs provide bright cooktop lighting to make preparation easy.
3-1/4" x 10" Damper
Easily connects to the 10" rectangular ductwork in your home.
Recirculation (Non-Vented/Duct-Free)
By not having to connect to outside air, this hood can be installed almost anywhere. Recirculation happens through filters to keep the air fresh. It's perfect for people in condos or those without existing ductwork.
Manufacturer's Warranty: 1 year
Canadian model: UXT4230ADB
Canadian UPC: 883049326474
EAN: 0883049326474
| Dimensions | |
| Depth | 18-5/8 in |
| Height | 4-15/16 in |
| Width | 29-15/16 in |
| Configuration and Overview | |
| Hood Type | Under-the-Cabinet |
| Prop 65 | CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov . |
| Size | 30 in |
| UL | UL |
| Details | |
| Number of Task Light Settings | 2 |
| Task Light Type | Incandescent |
| Task Lighting | Yes |
| Ventilation System | |
| Blower Type | Axial |
| Duct Direction | Vertical or Horizontal |
| Duct Outlet Size | 3 1/4 x 10 |
| Duct Type | Rectangular |
| Filters | Charcoal Odor Removing Filter, Grease Filters |
| Number of Speeds | 2 |
| Sound Max Speed Sones | 6-2/5 |
| Electrical | |
| Hz | 60 |
| GDS | |
| GPC Code | 10005322 |
| IsInvoiceUnit | true |
| IsOrderableUnit | true |
| Product Type | EA |
| UDEX | 1100642102 |
| isBaseUnit | true |
| isConsumerUnit | true |
| DIMENSIONS | |
| Height | 4 15/16 Inches |
| Depth | 18 5/8 Inches |
| Width | Other |
| Configuration and Overview | |
| Hood Type | Under Cabinet |
| Venting Type | Exterior or Recirculating |
| Fan CFM | 225 |
| Style and Extras | |
| Control Type | Push Button |
| Number of Fan Speeds | 2 |
| Removable Grease Filter | Yes |
| Task Light | Incandescent |
Use & Care Guide (UXT4230ADB-use-care-guide-canada.pdf)
