Zephyr AK8200AS
Discontinued
ARH3EX
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $101.00 for 18 months
Ratings & Reviews
Similar Colours and Options
AK8800AS
AK8800AS
Stainless Steel
ARH3EX
When will I get this?

Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $101.00 for 18 months
Description & Features
Tornado II, Power Pack, 29-13/16", SS, 1000 CFM
  • 1000 CFM
  • 8 Sones Max.
  • 2 Halogen Lamps, GU1035W
  • Dual Level Lighting
  • Electronic Touch Controls
  • 3 Speeds
  • Auto Delay-Off
  • RF Remote Control
  • Baffle Filters
  • 8" Round Vertical Ducting
  • Stainless Steel Liner (Optional)

Manufacturer's Warranty: 1 year

Canadian model: AK8200AS

Canadian UPC: 646328820069

EAN: 0646328820069

Specs
Brand Zephyr
Manufacturer Zephyr
Category Range Hood
Sub-Category Insert
Vent Type Ducted
UPC 646328820069
GTIN 00646328820069
Country of Origin Taiwan
Model Group AK82-A
Model Name Tornado II Insert
Collection Pro Collection
Replacement Model AK8200BS
Blower Included Yes
Internal Blower 1 CFM 1000
Internal Blower 1 Min. Sones 3.5
Internal Blower 1 Max Sones 8
Minimum CFM 500
Installation Type Insert
Installation Type Insert
For Outdoor Use No
Color Stainless Steel
Controls Type Electronic
Blower Speeds 3
Automatic Delay-Off Yes
Clean Air Function Yes
Lighting Type Halogen
Lights Quantity 2
Watts Per Bulb 35
Lights Levels 2
Grease Filter Type Pro baffle
Compatible Mesh or Baffle Filter Part Number 50210010
Duct Discharge Vertical
Duct Size; Horizontal; IN N/A
Duct Size; Vertical; IN 8
Mounting Height Above Cooktop; IN 26 - 36
Voltage 120
Maximum Amperage 6
ADA Compliant Yes
Warranty Parts / Labor 10 / 1
Compatible Appliances AK0806AS, AK0842AS, MUA008A, Z0B0040
Bluetooth Connected No
Wi-Fi Connected No
Remote Included No
Remote Optional No
Energy Star Certified No
Alexa & Google Home Compatible No
CEC Title 20 Compliant Yes
Primary Material Stainless Steel
Wattage 720
Certification UL
Nominal Width; IN 30
Net Width; IN 29.8125
Net Depth; IN 15.8125
Net Height; IN 11.4375
Weight; LBS 39.7
Ceiling Height Minimum 8 ft.
Ceiling Height Maximum 12 ft.
Shipping Length; IN 21.38
Shipping Width; IN 34.02
Shipping Height; IN 16.69
Shipping Weight; LBS 43
Shipping Method Small Parcel
Freight Class 175
Certification # E127334
Clean Filter Alert Yes
Duct Type Vertical
Duct Type Vertical
Performance
Internal Dual Blower:
1000 CFM
Sones:
8
Features
Controls:
Electronic Touch
Speed Levels:
3
Auto Delay-Off:
Yes
Lighting:
Halogen, 35W x 2
Dual-Level Lighting:
Yes
Filters:
Baffle
Recirculating:
No
RF Remote Control:
Yes
Specifications
Vertical Ducting:
8" Round
Horizontal Ducting:
N/A
AC Input:
120V - 60Hz
AC Power:
Max. 710W at 5.95 Amps
Dimensions
Width:
29 13/16"
Depth:
15 13/16"
Height:
16 7/16"
Cabinet Bottom Cutout Width:
26 1/16"
Cabinet Bottom Cutout Depth:
14 3/4"
Min. Height Accomodations:
Min. Height 26" From Cooking Surface; Hood Mounted 62" From Floor.
Max. Height Accomodations:
Max. Height 36" Above Cooking Surface; Hood Mounted 72" From Floor.
