JennAir JDS8860BDP
Discontinued
>> View 2020 JennAir Parts & Accessories Guide << >> View 2020 JennAir Parts & Accessories Guide <<
4QL59I
4QL59I
When will I get this?

Description & Features
Overview
This Jenn-Air® luxury duel-fuel range offers the precision of gas and the consistent heat of electric. Its four burners include a versatile 15,000 BTU burner that can go as low as 750 BTUs for precise and gentle heat. It also features powerful MultiMode® convection, which provides beautifully even baking and roasting.

Specifications
Configuration and Overview
  • Fuel Type: Dual Fuel
  • Range Type : Slide-in
  • Size: 30
  • Capacity: 4.5

Cooktop Features
  • Cooktop Element Style: Sealed Burner
  • Cooktop Surface Color: Black
  • Cooktop Surface Material: Porcelain Coated Steel
  • Number of Cooking Element-Burners: 4
  • Left Front Element-Burner Power: 15000 BTU
  • Left Front Element-Burner Type: Sealed Burner
  • Left Rear Element-Burner Power: 9200 BTU
  • Left Rear Element-Burner Type: Sealed Burner
  • Right Front Element-Burner Power: 16000 BTU
  • Right Front Element-Burner Type: Sealed Burner
  • Right Rear Element-Burner Power: 5000 BTU
  • Right Rear Element-Burner Type: Simmer
  • Dishwasher Safe: No
  • Grate Finish: Matte
  • Grate Material: Cast Iron
  • Grate Type: Continuous
  • Number of Grates: 2

Dimensions
  • Depth: 29 1/8
  • Height: 37 1/4
  • Width: 30 3/4

Oven Features
  • Convection Bake: Yes
  • Convection Broil: Yes
  • Self-Cleaning : Self-Cleaning
  • Automatic Convection Conversion Temperature Adjust: Yes
  • Heating Element On Indicator Light: No
  • Hot Surface Indicator Light: No
  • Power On Indicator Light: Yes
  • Broiler Location: Top of Oven
  • Convection Element Type: Dual-Fan
  • Convection Functions: Bake, Broil, Roast
  • Hidden Bake: Yes
  • Light Type: Halogen
  • Number of Oven Lights: 1
  • Number of Oven Racks: 3
  • Number of Rack Guides: 5
  • Oven Cooking System: Convection
  • Oven Rack Type: Standard
  • Self-Cleaning : Yes

Style and Extras
  • Door Type: Metal & Glass
  • Handle Material: Metal
  • Selections: Bread Proofing, Clock, Control Lock, Cook and Hold, Delay Start, Hidden Bake Element, Power Outage Compatible, Sabbath Mode, Simmer, Warm Hold
  • ADA Compliant: ADA Height and Operation Compliant
  • UL: Yes


  • Signature Features
  • Electronic Ignition and Flame-Sensing™ Re-ignition
  • EvenThree™ Burner
  • Auto Convection Conversion
  • 2-Speed MultiMode® Convection System
  • Cooking Surface Control Features
  • Infinite Burner Control Settings
  • Cooking Surface Features
  • 16,000 BTU PowerBurner
  • 4 Sealed Burners
  • 9,200 BTU Burner
  • Convertible to LP
  • 5,000 BTU Ultra-Low Output Burner
  • Oven Control Features
  • Control Lockout
  • Control Setup Options
  • Cook & Hold Option
  • Delay-Start Cooking & Cleaning
  • Electronic Clock with Two Timers
  • Favorite Setting(s) Option
  • Keep Warm™ Option
  • Menu-Driven Electronic Oven Controls
  • Proofing Option
  • Sabbath Mode
  • Rapid Preheat
  • Temperature Probe
  • Oven Features
  • 8-Pass Recessed Broil Element
  • 3 Heavy-Duty Racks
  • 4.5 Cu. Ft. Oven Capacity
  • CustomClean™ Self-Cleaning with Adjustable Levels and Automatic Lock
  • Hidden Bake Element
  • Temperature-Controlled Preheat
  • Variable Temperature Broil
  • 3,400-Watt Convection Element
  • 3,600-Watt Broil Element
  • Halogen Light
  • Warming Drawer with Preset Temperature Settings
  • 2,800-Watt Bake Element
  • Exterior Design Features
  • Stainless Steel Handle with Diamond-Etched Grip
  • Black Satin-Matte Grates and Burner Caps
  • Extra-Large Panaview™ Oven Window
  • Porcelain-on-Cast-Iron Grates
  • Oversized Stainless Steel Knobs

  • Bread Proofing, Cook & Hold, Favorite Settings, Rapid Preheat And Keep Warm Oven Options.
  • Customization Options Include English, French Or Spanish Language, True Sabbath Mode And Fahrenheit Or Celsius Display.
  • Delay-Start Cooking And Cleaning.
  • Help Option.
  • Infinite Surface Control Settings.
  • Integrated Control Panel With No Trim Or Frame.
  • Menu-Driven Electronic Controls Include Clock With Two Timers.
  • Pro-Style« Stainless Design Featuring Commercial Style Stainless Steel Surfaces And Stainless Steel Towel Bar Handles With Diamond-Etched Grip. Back to Top
  •
  • Cooking Surface
  • 15,000/3,000/750 BTU EvenThreeÖ Sealed Burner. v
  • Black Satin Matte Burner Grates And Caps.
  • Electronic Ignition With Flame-SensingÖ Reignition.
  • Four Sealed Gas Burners.
  • Low Output 5,000 BTU Burner Reduces To Ultra-Low 650 BTUs.
  • One-Piece Porcelain-On-Cast Iron Burner Grates. Smart Port Gas Burner Design. Ultra-High Output 16,000 BTU PowerBurner.
  • Accepts Optional Cooking Accessories.
  • Convertible To LP Gas.
  • Gas Cooking Surface Combined With
  • Electric Oven (Dual-Fuel).
  • Optional Backsplashes Available.
  • Warming Drawer.
  • 4.5 Cu. Ft. Oven Capacity.
  • Auto Convection Conversion.
  • Conventional Bake, Roast And Broil Capabilities.
  • CustomCleanÖ Self-Cleaning Oven With Auto-Lock.
  • Eight-Pass Recessed Broil Element.
  • Extra-Large PanaviewÖ Oven Window.
  • Halogen Lighting Of The Oven Interior.
  • Hidden Bake Element In Oven Floor.
  • MultiMode« Convection Includes Convect Bake, Roast, Pastry, Drying And Thaw And Serve Options.
  • Temperature Probe.
  • Three Oven Racks.
  • Variable Temperature Broiling That Allows For Adjustment From 300¦ To 550¦

Manufacturer's Warranty: 2 years

Specs
Burner Detail
Burner Type Sealed
Ignition Type Electronic w/ Flame Chamber
Left Front Brnr High Nat (BTU) 15000
Left Front Brnr Low Nat (BTU) 3000
Left Front Burner Type EvenThree
Left Rear Brnr High Nat (BTU) 9200
Right Front Brnr High Na (BTU) 16000
Right Front Burner Type PowerBurner
Right Rear Brnr High Nat (BTU) 5000
Right Rear Burner Type Simmer Burner
Cooking Surface Controls
Quantity of Knobs 4
Type (Switch/Rotation Degrees) Electro. Mechanical
Cooktop Specs
Cooktop Color Black
Cooktop Type Porc./Steel
Gas Specifications
LP Gas Convertible Yes
Grate Detail
Grate Color Black
Grate Material Porcelain Coated Cast Iron
Lower Panel - Drawer
Drawer Type Warming Drawer
Model
Fuel Type Dual Fuel
Oven Controls
Oven Control Location Manifold
Oven Features
Bread Proofing Yes
Clock Yes
Control Lockout Yes
Convection Bake Yes
Convection Broil Yes
Convection Roast Yes
Cook and Hold Yes
Dehydrate Yes
Delayed Cooking Option Yes
Favorites Yes
Kitchen Timer Yes
Oven Light Switch Touch Pad
Preheat Type Temp
Sabbath Mode Yes
Warm Hold Yes
Oven Interior
Broiler Number of Passes 8
Cleaning System Self
Number Oven Racks 3
Oven Capacity 4.5
Oven Light Type Halogen



Performance
Fuel Type Dual Fuel
Cooktop Features
Left Front Burner (BTU) 15000
Right Front Burner (BTU) 16000
Left Rear Burner (BTU) 9200
Right Rear Burner (BTU) 5000
Oven Features
Total Capacity 4.5 Cu. Ft.
Convection Bake Yes
Convection Roast Yes
Convection Conversion Yes
Bake Yes
Cleaning System Self-Cleaning
Temperature Probe Yes
Hidden Bake Element Yes
Sabbath Mode Yes
Delayed Cooking Yes
Favorites 10
Warm Hold Keep Warm™ Option
Cook and Hold Yes
Bread Proofing Yes
Drawer Type Warming Drawer
Convection Element Wattage @120v 3400
Design
Cooktop Material Porcelain
Grate Material Cast
Oven Controls Menu-Driven Electronic Controls with Prompts
Hot Surface Indicator Light(s) Yes
Delayed Cooking Yes
Dimensions
Product Height 36 Inches
Product Depth 28 1/4 Inches
Product Width 29 7/8 Inches
