JennAir JED8230ADS
Discontinued
>> View 2020 JennAir Parts & Accessories Guide << >> View 2020 JennAir Parts & Accessories Guide <<
ADJUZQ
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
2 years manufacturer warranty included
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $92.73 for 18 months
Ratings & Reviews
ADJUZQ
When will I get this?

Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
2 years manufacturer warranty included
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $92.73 for 18 months
Description & Features
Overview
This Jenn-Air® luxury modular electric downdraft cooktop offers the flexibility to reconfigure the cooking surface to suit your preferred cooking style, as well as the ability to grill indoors. It features Designer Line styling and a built-in ventilation system that clears the air without a hood.

Specifications
Configuration and Overview
  • Cooktop Type: Modular Downdraft
  • Cooktop Type: Modular Downdraft
  • Size: 30
  • Size: 30
  • Surface Material: Porcelain Coated Steel
  • Surface Material: Porcelain Coated Steel
  • Burner or Element Style: Radiant
  • Burner or Element Style: Radiant
  • Number of Burners: 2
  • Number of Burners: 2
  • Number of Open Bays: 1 Cartridge Sold Separately
  • Number of Open Bays: 1 Cartridge Sold Separately
  • Installs Over Built-In Oven: No
  • Installs Over Built-In Oven: No
  • ADA Compliant: No
  • ADA Compliant: No
  • Fuel Type: Electric
  • Fuel Type: Electric

Controls
  • Downdraft Vent: Yes
  • Downdraft Vent: Yes
  • Hot Surface Indicator Light: No
  • Hot Surface Indicator Light: No

Cooktop Features
  • Left Front Power: 1900W
  • Left Front Power: 1900W
  • Left Front Type: Grill
  • Left Front Type: Grill
  • Left Rear Power: 1900W
  • Left Rear Power: 1900W
  • Left Rear Type: Grill
  • Left Rear Type: Grill

Dimensions
  • Depth: 21 3/4
  • Depth: 21 3/4
  • Height: 13 13/16
  • Height: 13 13/16
  • Width: 30
  • Width: 30
  • Cutout Depth: 21
  • Cutout Depth: 21
  • Cutout Width: 29
  • Cutout Width: 29

  • Signature Features
  • Interchangeable grills, cartridges and accessories (sold separately)
  • Control Features
  • Color-Coordinating Knobs
  • 2 "On" Indicator Lights
  • Cooking Surface Features
  • Indoor Grilling Capability
  • Ships with One Open Bay
  • Countertop or Island/Peninsula Installation without Overhead Ventilation Hood
  • Features
  • 325 CFM Rating
  • Exterior Design Features
  • Porcelain-Enamel/Stainless Steel Surface
  • Excalibur® Nonstick Grill Grate Finish



Burners

  • Removable, porcelain dishwasher-safe grill liner pan
  • Colour-Coordinated Control Knobs

Controls

  • Infinite control settings
  • "On" Indicator Lights: 2

Exterior

  • Available in black, white or stainless steel.

Flexibility

  • Grilling capacity in both bays
  • Modular design
  • Comes with grill assembly and one open bay.
  • Open bay accepts halogen, radiant or coil element cartridge, or additional grill assembly.
  • Countertop or island/peninsula installation without Overhead Ventilation Hood
  • Accepts Optional Accessories
  • Grill Assembly with 1900w Element and Removable Porcelain Liner Pan.
  • Accepts Optional Grill Assembly
  • Accepts Optional Radiant and/or Coil Element Cartridge.

Surface

  • Two-speed ventilation fan
  • Control panel with door alarm, temperature alert, Max Cool and Speed Ice™
  • Excalibur® nonstick grill grate finish
  • Downdraft ventilation

Specifications

  • Total Connected Load: 8 kW
  • Approximate Shipping Weight: 66 lbs/ 30 kgs



Manufacturer's Warranty: 2 years

Canadian model: JED8230ADS

Specs
Cooking Surface Controls
Color Color Coordinated
Location Surface Center Front
Material Plastic
Power On Indicator Light Yes
Type (Switch/Rotation Degrees) Knobs
Cooktop Specs
Cooktop Material Porcelain on Steel
Cooktop Type Modular
Gas Specifications
LP Gas Convertible N/A
Model
Fuel Type Electric
Modular Cooktop
Number of Bays 2
Number of Empty Bays 1

Performance
Fuel Type Electric
Element Type Modular
Design
Cooktop Design Porcelain on Steel
Cooktop Controls Knobs
Dimensions
Product Height 13 13/16 Inches
Product Width 30 Inches
Product Depth 21 3/4 Inches
