JennAir JGD8345ADW
Discontinued
>> View 2020 JennAir Parts & Accessories Guide << >> View 2020 JennAir Parts & Accessories Guide <<
AI3OTV
Ratings & Reviews
Description & Features

Enjoy a Double Benefit

Adorn your centre island or peninsula with the power and versatility that gas cooktops provide. Then bask in the fresh, clean air conferred by DownDraft technology, the unique ventilation system which helps rid you of unwanted grilling smoke and odours.


The ease and flavor of outdoor grilling is brought inside with this cooktop that features downdraft ventilation and an E-ven Heat™ grill assembly. Two 2-burner modules with sealed burners are also included, and an optional 2-burner module may be purchased for use in place of the grill.

  • Downdraft Ventilation System with 2-Speed Fan
  • A built-in downdraft ventilation system eliminates the need for an overhead hood by capturing smoke, steam and odors right at the cooking surface to help keep your kitchen air fresh.
  • Modular Design
  • A cooking surface with a modular design allows you to accommodate a variety of cooking methods. Interchangeable grills, cartridges and accessories (sold separately) are available to help you customize the cooking surface to your preferences.
  • Replaceable E-ven Heat™ Grill Assembly
  • This luxury downdraft rangetop's "E"-shaped burner delivers even heat across the entire grill surface, providing beautifully even indoor grilling.
  • Four Fixed Sealed Burners
  • The fixed sealed burners, which prevent spills and drips from entering the burner box, make it easy to maintain a pristine cooking surface.
  • Four 10,000 BTU Burners
  • Four 10,000 BTU Burners
  • Two 8,000 BTU Burners
  • Indoor Grilling Capability
  • The left side of this modular cooktop is designed to accommodate a grill module, giving you the option for indoor grilling.
  • Countertop/Island/Peninsula Install without Hood
  • Because it features a built-in downdraft ventilation system and doesn't require a hood, the rangetop offers exceptional design flexibility.
  • Color-Coordinating Knobs
  • Color-coordinating knobs blend beautifully with the cooktop exterior for a streamlined look.
  • Electronic Ignition
  • A method of ignition in which the gas is ignited at the burner port by an electric spark.
  • Infinite Burner Control Settings
  • Enjoy precise controls by selecting your preferred burner setting - from low to high and everywhere in between.
  • Porcelain-on-Cast-Iron Continuous Grates
  • These heavy-duty grates, which feature a porcelain coating to withstand high temperatures, form a continuous grid across the cooktop, allowing you to easily slide heavy pans from one burner to another.
  • Excalibur® Nonstick Grill Grate Finish
  • A finish on Jenn-Air® grill grates that produces superior release capabilities through a four-step manufacturing process. It keeps food from sticking to the grill, making grilling and cleanup easy.
  • Porcelain-Enamel/Stainless Steel Surface
  • This surface transfers heat efficiently and is highly durable, with a subtle sheen that's easy to maintain.

Controls

  • Infinite Surface Control Settings.

    Cooking Surface
  • Downdraft Ventilation With Two-Speed Fan.
  • Electronic Pilotless Ignition.
  • Includes E-ven HeatÖ Grill Assembly With Excalibur Nonstick Grill Grate Finish.
  • Includes Two Two-Burner Modules With Sealed Burners.
  • Modular Design; Accepts Optional Two-Burner Gas Module In Place Of Grill.
  • One-Piece Porcelain-On-Cast Iron Burner Grates.

    Other
  • Accepts Optional Cooking Accessories.
  • Convertible To LP Gas.
  • Countertop Or Island/Peninsula Installation With No Overhead Hood Needed.

Manufacturer's Warranty: 2 years

Canadian model: JGD8345ADW

Specs
Burner Detail
Burner Type Sealed
Center Rear Brnr Low LP (BTU) 1650
Centr Front Brnr High Na (BTU) 10000
Centr Rear Brnr High LP (BTU) 9000
Centr Rear Brnr High Nat (BTU) 10000
Centr Rear Brnr Low Nat (BTU) 1650
Ignition Type Electronic
Left Front Brnr High LP (BTU) 7500
Left Front Brnr High Nat (BTU) 8000
Left Front Brnr Low Nat (BTU) 4000
Left Rear Brnr High Nat (BTU) 8000
Left Rear Burner High LP (BTU) 7500
Left Rear Burner Low Nat (BTU) 4000
Right Front Brnr High LP (BTU) 9000
Right Front Brnr High Na (BTU) 10000
Right Front Brnr Low Nat (BTU) 1500
Right Rear Brnr High LP (BTU) 9000
Right Rear Brnr High Nat (BTU) 10000
Right Rear Brnr Low Nat (BTU) 1500
Cooking Surface Controls
Color Color Coordinated
Location Split
Material Plastic
Type (Switch/Rotation Degrees) Knobs
Cooktop Specs
Cooktop Material Porcelain on Steel
Gas Specifications
LP Gas Convertible Yes
Grate Detail
Grate Color Black
Grate Material Porcelain on Cast Iron
Grate Type Continuous
Model
Fuel Type Natural Gas
Modular Cooktop
Number of Bays 1
