Description & Features
Overview
This Jenn-Air® luxury under counter wine cellar (with right-hand door swing) keeps your favorite bottles stylishly close at hand. It features two temperature zones, an LED temperature display and five roll-out racks to store up to 46 bottles.

Specifications
Dimensions
  • Height: 35 1/8
  • Width: 23 3/4
  • Depth: 24 3/8
  • Door Radius: 47
  • Depth Excluding Doors: 22
  • Cutout Height (in): 34 5/8
  • Cutout Width (in): 24
  • Cutout Depth (in): 24
  • Weight: 192

Product Specifications
  • Total Capacity: 5.6 Cu. Ft.


  • Signature Features
  • LED Temperature Display
  • 5 Roll-Out Racks
  • DualZone System
  • UV-Resistant Thermal Glass Door
  • Control Features
  • Adjustable Temperature Control
  • Refrigeration Features
  • Automatic Defrost
  • Stainable Maple Rack Fronts
  • 46-Bottle Capacity
  • Fixed Display Rack
  • 2 Temperature Zones
  • Automatic Interior Light
  • Exterior Design Features
  • Black Textured Cabinet Finish
  • Built-In or Freestanding Installation
  • 4 Adjustable Levelers

* Interior Features
    * 46-bottle capacity allows storage of a variety of wines suitable for every occasion
    * Dual temperature zones and adjustable temperature control allow different wines to be stored in one convenient place
    * Roll-out racks provide easy access, and the maple fronts may be stained to match surrounding cabinets
    * UV-resistant thermal glass door protects wine from light and harmful rays
    * LED temperature display provides constant feedback on temperatures inside the wine cellar
    * 5.6 cu. ft. capacity
    * 46-bottle capacity with space for 6 magnums
    * DualZone system
    * 5 roll-out racks with stainless steel ball bearing rollers
    * Stainable maple rack fronts

    * Other Features
    * Brushed stainless steel handle
    * Seamless edges
    * Right-hand door swing
    * Built-in or freestanding installation
    * Wrap around stainless steel door with black cabinet
    * LED temperature display for upper and lower zone
    * Fahrenheit and Celsius temperature display option
    * Auto defrost
    * Automatic interior light
    * Black interior
    * UV-resistant thermal glass door
    * Adjustable temperature control on base grille
    * Manual light switch
    *
    * Installation Notes
    * If your wine cellar is to be built-in, ensure proper ventilation by allowing for 1/4" space on each side and at the top.
    * When installing your wine cellar next to a fixed wall and the hinge side is next to the wall, leave 2 1/2" minimum to allow for the door to swing open.
    * To open the door wider, leave more space.
    * Do not install wine cellar near an oven, radiator or other heat source, nor in a location where the temperature will fall below 55° (13°C).




Manufacturer's Warranty: 2 years

Canadian model: JUW248RWRS

Specs
Configuration and Overview
Bottle Capacity 46
Controls
Control Location Base Grille
Control Type Electronic
Cooling On/Off No
Number of Temperature Controlled Zones 2
Controls
Shelf(s) Description 2 Wine Racks
Temperature Divider LED Color Blue
Temperature Divider LED Dimmer Switch Yes
Temperature Range 43F to 55F @ 70 Ambient
Zone 1 Capacity Up to 24 Bottles
Zone 1 Description White Wine
Zone 2 Capacity Up to 22 Bottles
Zone 2 Description Red Wine
Zone 2 Temperature Range 59F to 64F @ 70F Ambient
Annual Energy Usage [kWh] 441
Cabinet Finish Textured
Handle Location Vertical
Dimensions
Height 35 1/8
Width 23 3/4
Depth 24 3/8
Cutout Height (in) 34 5/8
Cutout Width (in) 24
Cutout Depth (in) 24
Depth with Door Open 90 Degrees 47
Depth Excluding Doors 22
Depth Closed Excluding Handles 24 3/8
Width of Cabinet Only 23 3/4

Dimensions
Width:     23 3/4"
Depth:     24"
Depth excl. Overlay Panel:     23 5/8"
Depth excl. Door:     21"
Depth incl. Handle:     26 1/2"
Depth with Door Open 90°:     47 1/2"
Clearance Required with Door open 90°:     23 1/4"
Height - Fully Extended:     34 3/4"
Height - Fully Retracted:     34 3/8"
Cutout Width (min.):     24"
Cutout Depth (min.):     24"
Cutout Height (min.-max.):     34 3/8" - 34 3/4"
Custom Panel Dimensions
Width:     23 5/8"
Height:     29 7/8"
Interior Capacity
Total Volume:     5.6 cu. ft.
Bottle Capacity:     up to 46 wine bottles
Specifications
Jenn-Air Platinum Warranty:     Yes
Available in Canada:     Yes
Kilowatt Hours per Year:     441
Approximate Shipping Weight:     192 lbs./87 kg
Wine Cellar Features
Adjustable Thermostat:     Yes
Automatic Defrost:     Yes
Temperature Zones:     Dual
Temperature Range - Upper Zone:     45° - 55°F
Temperature Range - Lower Zone:     56° - 64°F
Automatic Interior Light:     Yes
Roll-out Racks:     5
Fixed Rack:     1
Rack Color:     Black Gloss
Rack Trim:     Maple
Exterior Features
Cabinet Color:     Black
Cabinet Hinge (Top/Bottom):     Stainless Steel/Plated Nickel
Door Color:     Stainless Steel
Handle Color:     Euro-Style
Badge Location:     Centered (bottom of door)
Grille Color:     Black
