Gas Range Connection $189
(Includes Disconnecting Old Gas Unit)
Thermador SGS304FS
Discontinued
AX1A9M
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
2 years manufacturer warranty included
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $125.17 for 18 months
Ratings & Reviews
AX1A9M
When will I get this?

Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
2 years manufacturer warranty included
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $125.17 for 18 months
Description & Features

Thermador Masterpiece Series SGS304FS Gas Cooktop 30 in with 4 Star Burners, 16,000 BTU Power Burner, Electronic Re-Ignition and Continuous Grates

It's the most powerful 30-inch gas cooktop on the market. With our fourth generation Star® Burner, you get more heat on the pan for faster cooking and a smaller cool spot.
  • Innovation
  • Patented and exclusive Star Burner provides superior performance
  • Unique shape of the Star Burner offers wider heat coverage resulting in smaller cold spots
  • Performance
  • Powerful 16,000 BTU Burner
  • Continuous grates allow pots and pans to glide smoothly across the cooktop
  • Automatic electronic re-ignition
  • Knobs feature a safety "push to turn" system
  • Design
  • Chiseled, angular design coordinates with the suite of Thermador Masterpiece Collection appliances
  • High-grade, quality die cast metal knobs

Design

  • High-grade, quality die cast metal knobs
  • Chiseled, angular design coordinates with the suite of Thermador Masterpiece™ Collection appliances

Performance

  • Patented and exclusive Star® Burner provides superior performance
  • Unique shape of the Star® Burner offers wider heat coverage resulting in smaller cold spots
  • Powerful 16,000 BTU Burner
  • Continuous grates allow pots and pans to glide smoothly across the cooktop

Safety

  • Knobs feature a safety "push to turn" system
  • Automatic electronic re-ignition




Manufacturer's Warranty: 2 years

Canadian model: SGS304FS

Canadian UPC: 825225853244

EAN: 0825225853244

Specs
Technical Specifications
Energy source Gas
Type of control sword knobs
Safety device automatic reignition
Construction type
Color of frame Stainless steel
Color of surface Stainless steel
Installation type Built-in
Number of electric elements 0
Number of electric cooking zones 0
Number of gas burners 0
Number of halogen elements 0
Installation Type Built-in
Type of grate Cast iron
Number of radiant elements 0
Number of electric warming zones 0
Size and weight
Overall appliance dimensions (HxWxD) (mm) 96.8 x 787 x 546 mm
Net weight (kg) 18.471 kg
Cooking zone 1
Location of 1st heating element front left
Cooking zone 2
Location of 2nd heating element center left
Cooking zone 3
Location of 3rd heating element back left
Cooking zone 4
Location of 4th heating element middle back
Cooking zone 5
Location of 5th heating element back right
Cooking zone 6
Location of 6th heating element center right
Cooking zone 7
Location of 7th heating element front right
Cooking zone 8
Location of 8th heating element front middle / central
Cooking zone 9
Location of 9th heating element front centre/cent
Safety
Type of safety device for gas Without
Power on indicator No
Residual heat indicator without
Safety device automatic reignition
Main on/off switch No
Connection
Power cord length (cm) 152 cm
Watts (W) 1,800 W
Energy source Gas
Frequency (Hz) 60 Hz
Location of gas connection bottom, rear, right
Gas connection rating (W) 12,890 W
Accessories
Included accessories 3 x cast iron pan support



Technical Specifications

Amps (A)

15

Frequency (Hz)

60

Gas type

Natural gas 15 mbar (USA)

Alternative gas type

Liquid gas 27,5 mbar (USA)

Approval certificates

CSA

Plug type

120V-3 prong

Minimum distance from counter front (in)

1 7/8''

Minimum distance from rear wall (in)

3''

Net weight (lbs)

37

Gross weight (lbs)

45









Product Features

Type of grate

Cast iron

Number of double grates

2

Optional accessories

SNLPKITF, SWOKRINGF

Knob material

Full metal

Natural gas connection rating (BTU)

44000

LP Gas Connection Rating (BTU)

39200

Sealed burners

Yes

Number of single grates

1

Included accessories

3 x cast iron pan support

Location of 1st heating element

front left

Power of 1st burner (BTU)

10000

Location of 2nd heating element

back left

Power of 2nd burner (BTU)

10000

Location of 3rd heating element

back right

Power of 3rd burner (BTU)

8000

Location of 4th heating element

Cooking zone front right

Power of 4th burner (BTU)

16000
