Description & Features

The high-performance Whirlpool WEG760H0DS front control slide-in gas range with True Convection eliminates unnecessary meal preparation behind, with a range that fits your kitchen and delivers exquisite results. Its True Convection system works to seal in juices and flavor, delivers perfect results in less time than conventional ovens. For your convenience, you can skip the pre-heat, and cook frozen foods with the advanced Frozen Bake™ technology. Whirlpool’s versatile five-burner range offers the power and flexibility you need to create culinary masterpieces in your kitchen. Thanks to the FIT system, this slide-in range installs flush with your current cabinetry, giving your kitchen a premium, seamless look.



The sleek design of the Whirlpool WEG760H0DS slide-in gas range installs flush with your current cabinetry cutout thanks to the FIT system. This full-depth front-control range upgrades your kitchen with its seamless, built-in look without the hassle of remodeling. Its heavy-duty steel coated porcelain five-burner gas cooktop with black continuous grates sits flush with your cooktop.



The cooktop setup:

  • Left front burner: SpeedHeat™ burner with 17,000 BTU heat output
  • Left rear burner: 5,000 BTU heat output
  • Right front burner: SpeedHeat™ burner with 15,000 BTU heat output
  • Right rear burner: 9,200 BTU heat output
  • Center rear burner: 8,000 BTU heat output



Whirlpool’s powerful SpeedHeat™ burners were carefully designed to generate the high heat needed to achieve rapid boiling, searing, and pan frying on the cooktop, with burners offer heat levels ranging from 15,000 BTU to 17,000 BTUs. Thanks to Whirlpool this cooktop is well equipped to execute all of your favorite high-heat cooking techniques.



The Whirlpool WEG760H0DS proudly boasts a king-sized 5.8 cubic-foot capacity True Convection oven. This extra-large oven is equipped with three oven racks, and seven rack guides so you can customize the interior configuration of the oven cavity to meet your cooking, baking, roasting and broiling needs. You can prepare large turkeys and casseroles simultaneously with the adjustable interior setup, and receive the same great results on each rack thanks to the advance True Convection system and AccuBake® temperature management system.



The True Convection system seals in flavor and texture, while reducing roasting time by 12-%. This convection system uses a fan and third heating element installed in the rear of the oven to circulate heated air throughout the oven cavity evenly to achieve these outstanding results. This air circulation system distributes air under and around food, baking and roasting quicker than conventional ovens.



The advanced AccuBake® temperature management system works with the convection system to deliver outstanding baking results. This system uses built-in sensors to monitor the oven temperature and cooking elements, to deliver even consistent heat during the cooking time.



With this incredible Whirlpool oven, you can skip the preheat and cook frozen foods 31-% faster than you could with your old range. This range features Frozen Bake™ technology, so you simply select the food type, temperature, cook time, load the oven and walk away. You no longer need to wait an additional 15-20 minutes for your oven to preheat before you can bake a pizza or chicken nuggets.


Whirlpool® 5.8 cu. ft. Slide-In Gas Range with TimeSavor™ Plus True Convection


Leave unnecessary meal prep behind with the 5.8 cu. ft. front control gas range that fits your kitchen and delivers delicious results. True convection cooking helps seal in flavor and juices for perfect results in less time than non-convection ovens. You'll be able to skip the preheat and cook frozen favorites faster in this 5-burner gas range with Frozen Bake technology. And thanks to the FIT system, it's easy to upgrade to a full-depth slide-in range made to fit in your existing kitchen cutout. When it's time for cleanup, AquaLift self-cleaning technology helps you wipe away messes in your slide-in gas range without harsh chemicals or odors.


  • 5.8 Cu. Ft. Capacity
  • The 5.8 cu. ft. oven has room to bake and roast holiday dishes, so there's always enough space to handle even your largest meals.
  • Frozen Bake Technology
  • Frozen Bake technology cooks frozen foods faster 2 by eliminating the need to preheat the oven. Just select the food type, temperature and cook time listed on the frozen item's package and the oven will start customizing. Now you can cook frozen pizza 31% faster 1 , and even lasagna, chicken nuggets, fries and pies can get from the oven to the table in less time.
  • Full-Depth Front-Control Range with the FIT System
  • Upgrade to a full-depth front-control range that fits seamlessly in your kitchen without the hassle of remodeling thanks to the FIT system.
  • True Convection Cooking System
  • Seal in flavor and juices and cut roasting time by 12% with true convection cooking. A rear fan and a third heating element in the back of the oven circulate hot air over, under and around food to bake quicker than an oven without true convection.
  • AccuBake® Temperature Management System
  • The AccuBake® temperature management system's built-in sensor monitors oven temperature and the cooking elements to deliver consistent, delicious results every time.
  • SpeedHeat Burner
  • Generate the high heat needed for rapid boiling, searing and frying with burners that offer 15,000 or 17,000 BTUs.
  • Rapid Preheat
  • Put dinner on the table faster with Rapid Preheat, which uses the bake and broil elements to heat the oven quickly and efficiently. Ideal for single rack baking, this option saves time with 21% faster preheating.
  • AquaLift® Self-Cleaning Technology
  • AquaLift® self-cleaning technology delivers odor-free oven cleaning without chemicals in only 50 minutes 3 .
  • Full-Width, Satin-Finish Cast-Iron Grates
  • Cast-iron grates cover the whole cooking surface, giving you the flexibility to place pots and pans anywhere on the cooktop. The grates are dishwasher safe, and their satin finish resists wear and tear.

 Features


  • 5.8 Cu. Ft. Capacity
  • The 5.8 cu. ft. oven has room to bake and roast holiday dishes, so there's always enough space to handle even your largest meals
  •
  • Frozen Bake Technology
  • Cook frozen foods faster with Frozen Bake technology that eliminates the need to preheat the oven for favorites like pizza, lasagna, chicken nuggets, fries or pies
  •
  • Full-Depth Slide-In Range with the FIT System
  • Upgrade to a full-depth slide-in range that fits seamlessly in your kitchen without the hassle of remodeling thanks to the FIT system
  •
  • AquaLift Self-Cleaning Technology
  • AquaLift self-cleaning technology delivers odor-free oven cleaning without chemicals in only 50 minutes
  •
  • TimeSavor Plus True Convection Cooking
  • TimeSavor Plus true convection cooking uses a rear fan and a third heating element in the back of the oven to seal in flavor and juices
  •
  • AccuBake Temperature Management System
  • The AccuBake temperature management system's built-in sensor monitors oven temperature and the cooking elements to deliver consistent, delicious results every time
  •
  • SpeedHeat Burner
  • Generate the high heat needed for rapid boiling, searing and frying with burners that offer 15,000 or 17,000 BTU's
  •
  • Rapid Preheat
  • Rapid Preheat uses the bake and broil elements to heat the oven quickly and efficiently
  •
  • Full-Width, Satin-Finish Cast-Iron Grates
  • These dishwasher-safe grates cover the whole cooking surface, giving you the flexibility to place pots and pans anywhere on the cooktop

Manufacturer's Warranty: 1 year

Canadian model: WEG760H0DS

Specs
Configuration and Overview
Size 30
Capacity 5.8
Fuel Type Gas
Range Type Slide-in
Cooktop Features
Cooktop Element Style Gas Burner
Left Front Element-Burner Power 17,000 BTU
Cooktop Surface Material Porcelain Coated Steel
Center Rear Element-Burner Power 8000 BTU
Number of Grates 2
Left Rear Element-Burner Power 5000 BTU
Grate Type Continuous
Left Front Element-Burner Type SpeedHeat™
Cooktop Surface Color Black
Grate Material Cast Iron
Left Rear Element-Burner Type Burner
Right Front Element-Burner Type SpeedHeat™
Grate Finish Matte
Dishwasher Safe Yes
Right Rear Element-Burner Type Burner
Right Rear Element-Burner Power 9200 BTU
Right Front Element-Burner Power 15,000 BTU
Number of Cooking Element-Burners 5
Oven Features
Convection Functions Bake, Broil, Roast
Hot Surface Indicator Light No
Number of Oven Lights 1
Heating Element On Indicator Light Yes
Convection Element Type True
Broiler Element Power 13000 BTU
Power On Indicator Light Yes
Automatic Convection Conversion Temperature Adjust No
Oven Rack Type 1 Max Capacity, 2 Standard
Light Type Incandescent
Number of Rack Guides 7
Bake Element Power 18000 BTU
Self-Cleaning AquaLift® Steam Clean
Oven Cooking System Convection
Convection Element Power 900
Broiler Location Top of Oven
Hidden Bake Element Yes
Controls
ADA Compliant ADA Height and Operation Compliant
Star K Compliant Sabbath Mode
Selections AquaLift Self Clean, Bake, Broil, Control Lock, Convect Modes, Cook Time, Delay Start, Frozen Bake, Keep Warm Setting, Rapid Preheat, Settings
Handle Material Metal
UL Yes
Drawer Type Storage Drawer
Dimensions
Width 29 7/8
Height 36



Dimensions

Height 36 Inches
Width 29 7/8 Inches
Gross Weight 230 LB

Dimensions shown are for planning purposes only. For complete information, see Installation Instructions packed with product.

Specifications

Configuration and Overview
Fuel Type Gas
Size 30
Cooktop Features
Cooktop Element Style Gas Burner
Cooktop Surface Color Black
Cooktop Surface Material Porcelain Coated Steel
Number of Cooking Element-Burners 5
Center Rear Element-Burner Power 8000 BTU
Left Front Element-Burner Power 17000 BTU
Left Front Element-Burner Type SpeedHeat™
Left Rear Element-Burner Power 5000 BTU
Left Rear Element-Burner Type Burner
Right Front Element-Burner Power 15000 BTU
Right Front Element-Burner Type SpeedHeat™
Right Rear Element-Burner Power 9200 BTU
Right Rear Element-Burner Type Burner
Dishwasher Safe Yes
Grate Finish Matte
Grate Material Cast Iron
Grate Type Continuous
Number of Grates 2
Oven Features
Automatic Convection Conversion Temperature Adjust No
Heating Element On Indicator Light Yes
Hot Surface Indicator Light Yes
Power On Indicator Light Yes
Bake Element Power 240/208v 18000 BTU
Broiler Element Power 240/208v 13000 BTU
Broiler Location Top of Oven
Convection Element Power 900W
Convection Element Type True
Convection Functions Bake; Broil; Roast
Hidden Bake Element Yes
Light Type Incandescent
Number of Oven Lights 1
Number of Oven Racks 3
Number of Rack Guides 7
Oven Rack Type 1 Max Capacity, 2 Standard
Style and Extras
Drawer Type Storage Drawer
Handle Material Metal
Selections Frozen Bake; Bake; Broil; Control Lock; Convect Modes; Keep Warm Setting; AquaLift Self Clean; Cook Time; Delay Start; Rapid Preheat; Settings
ADA Compliant ADA Height and Operation Compliant
UL Yes
Dimensions
Height 36 Inches
Width 29 7/8 Inches
