Zephyr AK7500BS
Discontinued
AO9256
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $99.67 for 18 months
Ratings & Reviews
Similar Colours and Options
AK7000BS
AK7000BS
Dual Level Lighting
Stainless Steel
AK7500CS
AK7500CS
Stainless Steel
AO9256
When will I get this?

Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $99.67 for 18 months
Description & Features
Tempest II, 18in Pro, 30", SS, 650 CFM, ACT
Features
  • ACT (Airflow Control Technology) - ACT is a feature built into Tempest II hoods with single internal blowers allowing you to limit the maximum blower CFM to meet local code requirements.
  • 650 CFM
  • 1200 CFM, 9 Sones Dual Internal w/ 1 Blower Optional
  • 6 Sones Max.
  • 6 Speeds
  • Electronic Touch Controls
  • Halogen Lamps, 35W
  • Dual Level Lighting
  • 8" Round(Single)/10" (Dual) Round Vertical Ducting
  • 3-1/4" x 10" or 8" Round Horizontal Ducting (For Single Blower Only)
  • 3 Years Parts Warranty
  • 1 Year Labor Warranty
Optional Accessories
  • 12" Duct Cover
  • Wireless Remote
  • Dual Internal Blower Kit
  • Recirculating Kit
  • Backsplash with Shelves
  • Make-Up Air Kit, Single Blower
  • Make-Up Air Kit, Dual Blower

Manufacturer's Warranty: 1 year

Canadian model: AK7500BS

Canadian UPC: 646328003110

EAN: 0646328003110

Specs
Brand Zephyr
Manufacturer Zephyr
Category Range Hood
Sub-Category Wall
Vent Type Convertible
UPC 646328003110
GTIN 00646328003110
Country of Origin Taiwan
Model Group AK75-B
Model Name Tempest II
Collection Pro Collection
Replacement Model AK7500CS
Blower Included Yes
Blower CFM w/ACT 390, 290
Internal Blower 1 CFM 650
Internal Blower 1 Min. Sones 1
Internal Blower 1 Max Sones 6
Internal Blower 2 CFM 1200
Internal Blower 2 Max Sones 9
Minimum CFM 200
Installation Type Wall
Installation Type Wall
For Outdoor Use No
Color Stainless Steel
Controls Type Electronic
Blower Speeds 6
Automatic Delay-Off Yes
Clean Air Function Yes
Lighting Type Halogen
Lights Quantity 2
Watts Per Bulb 35
Lights Levels 2
Grease Filter Type Pro baffle
Compatible Mesh or Baffle Filter Part Number 50210015
Duct Discharge Vertical or Horizontal
Duct Size; Horizontal; IN 8, 10, 3.25 x 10
Duct Size; Vertical; IN 8, 10
Mounting Height Above Cooktop; IN 26 - 36
Voltage 120
Maximum Amperage 5
ADA Compliant Yes, with optional remote
Warranty Parts / Labor 3 / 1
Compatible Appliances PBD-1200A, ZRC-7000B, AK0720, 14000005, AK0710, MUA008A, MUA010A, Z0B0040, Z0F-C002
Bluetooth Connected No
Wi-Fi Connected No
Remote Included No
Remote Optional Yes
Energy Star Certified No
Alexa & Google Home Compatible No
CEC Title 20 Compliant Yes
Primary Material Stainless Steel
Wattage 480
Certification UL
Nominal Width; IN 30
Net Width; IN 29.875
Net Depth; IN 24
Net Height; IN 18
Weight; LBS 53.9
Ceiling Height Minimum 8 ft.
Ceiling Height Maximum 12 ft.
Shipping Length; IN 23.15
Shipping Width; IN 33.46
Shipping Height; IN 28.31
Shipping Weight; LBS 70.3
Shipping Method LTL
Freight Class 300
Duct Type Vertical
Duct Type Vertical
Performance
(Included)Internal Single Blower:
200-650 CFM
Internal Single Blower Sones:
1-6
Internal Optional Dual Blower:
400-1200 CFM
Internal Optional Dual Blower Sones:
2-9
Color
Stainless Steel:
SS
Features
ACT:
Yes
Controls:
Electronic Touch
Speed Levels:
6
Auto Delay-Off:
Yes
Clean Air Mode:
Yes
Lighting:
Halogen, 35W x 2
Dual-Level Lighting:
Yes
Filters:
SS Pro-Baffle x 2
Wireless Remote Control Option:
Yes
Dual Internal Blower Option:
Yes
Recirculating:
Yes (Optional Kit)
Duct Cover Extension:
12"
Specifications
Vertical Ducting:
8" (Single) Round/10" (Dual) Round
Horizontal Ducting:
3 1/4" x 10" or 8" Round (Single Blower Only)
AC Input:
120V - 60Hz
Single Blower AC Power:
Max. 4 Amps and 4.6 Amps
Dual Blower AC Power:
Max. 7.4 Amps and 8 Amps
Dimensions
Width:
29 7/8"
Depth:
24"
Height:
18"
Min. Height Accomodations:
Min. Height 26" From Cooking Surface; Hood Mounted 62" From Floor.
Max. Height Accomodations:
Max. Height 36" Above Cooking Surface; Hood Mounted 72" From Floor.
