Zephyr ALUE63AWX
Discontinued
B683WU
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $208.12 for 18 months
Ratings & Reviews
Similar Colours and Options
ALUE63ASX
ALUE63ASX
Stainless Steel
B683WU
When will I get this?

Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $208.12 for 18 months
Description & Features
Lux, Island, 63", Wht, BODY ONLY
Tri-Level LED Lighting
  • A three-level LED light strip to illuminate the cooktop.
CleanAir Function
  • A function to run the unit intermittently to keep the air clean even when not cooking.
Wireless Remote Control
  • Wireless remote included to easily control hood functions.
Capacitive Touch
  • Easy to use controls.
Aluminum Mesh Filters
  • Dishwasher safe mesh filters.
Certifications
  • A.D.A. Compliant

Manufacturer's Warranty: 1 year

Canadian model: ALUE63AWX

Canadian UPC: 646328006067

EAN: 0646328006067

Specs
Brand Zephyr
Manufacturer Zephyr
Category Range Hood
Sub-Category Island
Vent Type Convertible
UPC 646328006067
GTIN 00646328006067
Country of Origin Taiwan
Model Group ALU-A
Model Name Lux Island
Collection Designer Collection
Replacement Model ALU-E63BWX
Blower Included No
Internal Blower 1 CFM 290
Internal Blower 1 Min. Sones 1.4
Internal Blower 1 Max Sones 3
Internal Blower 2 CFM 600
Internal Blower 2 Max Sones 6
Internal Blower 3 CFM 1100
Internal Blower 3 Max Sones 8
In-Line Blower CFM 1000
External Blower CFM 1000
Installation Type Island
Installation Type Island
For Outdoor Use No
Color White
Controls Type Capacitive Touch
Blower Speeds 3
Automatic Delay-Off Yes
Clean Air Function Yes
Lighting Type LED
Lights Quantity 4
Watts Per Bulb 8.5
Lights Levels 3
Grease Filter Type Mesh
Compatible Mesh or Baffle Filter Part Number 50200058
Duct Discharge Horizontal
Duct Size; Horizontal; IN 6, 10
Duct Size; Vertical; IN N/A
Mounting Height Above Cooktop; IN 48 - 72
Voltage 120
Maximum Amperage 6.55
ADA Compliant Yes
Warranty Parts / Labor 1 / 1
Compatible Appliances ZRC-00LX, MUA006A, MUA008A, Z0F-01AC, 14000010, RC-0003
Bluetooth Connected No
Wi-Fi Connected No
Remote Included Yes
Remote Optional No
Energy Star Certified No
Alexa & Google Home Compatible No
CEC Title 20 Compliant Yes
Primary Material Steel
Certification UL
Nominal Width; IN 63
Net Width; IN 63.5
Net Depth; IN 27.5
Net Height; IN 14.375 - 23.875
Weight; LBS 92
Ceiling Height Minimum 6 ft.
Ceiling Height Maximum 9 ft.
Shipping Length; IN 31.5
Shipping Width; IN 66.9
Shipping Height; IN 17.32
Shipping Weight; LBS 97
Shipping Method LTL
Freight Class 300
Duct Type Horizontal
Duct Type Horizontal
Overview
Controls:
Capacitive Touch
Speed Levels:
3
Auto Delay-Off:
Yes
CleanAir Function:
Yes
Lighting:
LED Strip x3
Tri-Level Lighting:
Yes
Filters:
Aluminum Mesh
Wireless Remote Control:
Yes, RF
Recirculating Option:
Yes
Certifications
A.D.A. Compliant:
Yes
Dimensions & Weight
Width:
63 1/2"
Depth:
27 1/2"
Weight:
102 lbs
Electrical Specifications
Volts:
120V
Amps:
10A
Warranty
Parts & Labor:
1 Year Limited
