JennAir JED4536WS
Discontinued
>> View 2020 JennAir Parts & Accessories Guide << >> View 2020 JennAir Parts & Accessories Guide <<
ADG6PQ
Ratings & Reviews
ADG6PQ
When will I get this?

Description & Features
This Jenn-Air® luxury electric radiant downdraft cooktop with electronic touch controls offers a sleek design and responsive performance. Its glass touch controls and five radiant elements create a smooth, integrated cooktop surface, and the impressive JX3™ downdraft ventilation system quickly and efficiently clears the air without a hood. This cooktop pairs beautifully with our Euro-Style stainless suite.

  • Industry's Best Performing Ventilation System 1
  • JX3™ downdraft cooktops feature the industry's best performing ventilation system 1
  • JX3™ Downdraft Ventilation System with 3-Speed Fan
  • The powerful JX3™ downdraft uses proximity ventilation to capture smoke and cooking odors right at the cooking surface, to powerfully clear the air without requiring a hood.
  • Convertible to Duct-Free Ventilation
  • This luxury electric radiant downdraft cooktop is convertible to duct-free ventilation, allowing it to be placed nearly anywhere in the kitchen. With our duct-free conversion kit (not included), it creates a ventilation system that doesn't require running ductwork, ideal for kitchens with installation restrictions or ducting limitations.
  • Glass-Touch Electronic Controls
  • These sleek cooking controls feature a touch-responsive glass overlay integrated into the cooktop surface, with settings visible on an LED display.
  • 12"/9"/6" Triple-Choice™ Element
  • The Triple-Choice™ element allows you to match three different element sizes to cookware for more efficient, consistent heating.
  • Five Radiant Elements
  • These five fast-heating ribbon-shaped elements create heat from below the cooktop's sleek glass-ceramic surface.
  • Two 9"/6" Dual-Choice™ Elements
  • Two element sizes allow you to match your cookware to the appropriate size, for more consistent and efficient heating.
  • 7-Inch Keep Warm™ Element
  • Ideal for entertaining, this convenient 100-watt element offers a low temperature setting to keep already-cooked food perfectly warm, without further cooking.
  • 475 CFM Rating
  • This luxury electric radiant downdraft cooktop's ventilation system operates at up to 475 CFM to powerfully remove smoke, steam and cooking odors.
  • Easy-to-Clean Short Plenum
  • This plenum, which pulls the air through the ventilation chamber from its hidden position beneath the air grill, is easy to clean thanks to its short height.
  • Dishwasher-Safe Air Grill
  • This intake grill, which effectively captures smoke, grease and cooking odors as they're drawn through the system, can be easily cleaned in the dishwasher.
  • Delay Fan Feature
  • The fan will automatically turn off after 10 minutes, for more energy-efficient operation.
  • Ceran® Glass-Ceramic Surface
  • This sleek glass-ceramic cooking surface offers a high sheen that's easy to clean and maintain.

  • Industry's Best Performing Ventilation System
  • JX3™ Downdraft Ventilation System with 3-Speed Fan
  • Convertible to Duct-Free Ventilation
  • Glass-Touch Electronic Controls
  • 12"/9"/6" Triple-Choice™ Element
  • 5 Radiant Elements
  • Two 9"/6" Dual-Choice™ Elements
  • 6" 1,200-Watt Element
  • 7" Keep Warm™ Element
  • 475 CFM Rating
  • Easy-to-Clean Short Plenum
  • Dishwasher-Safe Air Grill
  • 5 Hot Surface Indicator Lights
  • Delay Fan Feature
  • Duct-Free Kit
  • Duct-Free Filter
  • Ceran® Glass-Ceramic Surface

Manufacturer's Warranty: 2 years

Canadian model: JED4536WS

Canadian UPC: 883049184128

EAN: 0883049184128

Specs
External Dimensions
Depth 22 1/8
Height 18 3/8
Width 35 1/2
Cutout Depth 21 1/8
Cutout Width 34 1/2
Key Features
Industry's Best Performing Ventilation System - JX3™ downdraft cooktops feature the industry's best performing ventilation system
JX3™ Downdraft Ventilation System with 3-Speed Fan - The powerful JX3™ downdraft uses proximity ventilation to capture smoke and cooking odors right at the cooking surface, to powerfully clear the air without requiring a hood.
Convertible to Duct-Free Ventilation - This luxury electric radiant downdraft cooktop is convertible to duct-free ventilation, allowing it to be placed nearly anywhere in the kitchen. With our duct-free conversion kit (not included), it creates a ventilation system that doesn't require running ductwork, ideal for kitchens with installation restrictions or ducting limitations.
Glass-Touch Electronic Controls - These sleek cooking controls feature a touch-responsive glass overlay integrated into the cooktop surface, with settings visible on an LED display.
12"/9"/6" Triple-Choice™ Element - The Triple-Choice™ element allows you to match three different element sizes to cookware for more efficient, consistent heating.
Five Radiant Elements - These five fast-heating ribbon-shaped elements create heat from below the cooktop's sleek glass-ceramic surface.
Two 9"/6" Dual-Choice™ Elements - Two element sizes allow you to match your cookware to the appropriate size, for more consistent and efficient heating.
7-Inch Keep Warm™ Element - Ideal for entertaining, this convenient 100-watt element offers a low temperature setting to keep already-cooked food perfectly warm, without further cooking.
475 CFM Rating - This luxury electric radiant downdraft cooktop's ventilation system operates at up to 475 CFM to powerfully remove smoke, steam and cooking odors.
Easy-to-Clean Short Plenum - This plenum, which pulls the air through the ventilation chamber from its hidden position beneath the air grill, is easy to clean thanks to its short height.
Dishwasher-Safe Air Grill - This intake grill, which effectively captures smoke, grease and cooking odors as they're drawn through the system, can be easily cleaned in the dishwasher.
Delay Fan Feature - The fan will automatically turn off after 10 minutes, for more energy-efficient operation.
Ceran® Glass-Ceramic Surface - This sleek glass-ceramic cooking surface offers a high sheen that's easy to clean and maintain.
Specifications
Configuration and Overview
Cooktop Type Downdraft
Fuel Type Electric
Size 36
Installs Over Built-In Oven No
Burner or Element Style Radiant
Cooktop Surface Material Ceramic Glass
Number of Cooking Element-Burners 5
ADA Compliant No
Amperage 40 Amps
Cooktop Features
Center Front Element-Burner Power 100W
Center Front Element-Burner Size 7"
Center Front Element-Burner Type Warming
Center Rear Element-Burner Power 2200W
Center Rear Element-Burner Size 9"/6"
Center Rear Element-Burner Type Dual
Left Front Element-Burner Power 2200W
Left Front Element-Burner Size 9"/6"
Left Front Element-Burner Type Dual
Left Rear Element-Burner Power 1800W
Left Rear Element-Burner Size 6"
Left Rear Element-Burner Type Radiant
Right Rear Element-Burner Power 3000W
Right Rear Element-Burner Size 12"/9"/6"
Right Rear Element-Burner Type Triple
Controls
Digital Display Yes
Downdraft Vent Yes
Heating Element On Indicator Light Yes
Hot Surface Indicator Light Yes
Control Type Electronic Touch

Dimensions
Cutout Width (in) 34 1/2 Inches
Cutout Depth (in) 21 1/8 Inches
