Description & Features

Four sealed burners, including a 15,000 BTU ultra-high output burner and a 5,000 BTU burner that reduces to ultra-low 650 BTUs, provide cooks the heat control needed for recipes requiring precise temperatures. The burners are built directly into the glass-ceramic surface, with no seams or burner bowls to trap spills, making this sleek cooktop as practical as it is beautiful.

Overview
This Jenn-Air® luxury gas cooktop offers power and precision along with a sleek glass-ceramic surface. It features four burners, including a 15,000 BTU ultra-high output burner. It also offers a lower-heat 5,000 BTU burner, which provides more gentle heat.

Specifications
Configuration and Overview
  • Cooktop Type: Standard
  • Size: 30
  • Fuel Type: Gas
  • Surface Material: Ceramic Glass
  • Burner or Element Style: Gas Burner
  • Number of Burners: 4
  • Installs Over Built-In Oven: Yes

Cooktop Features
  • Left Front Power: 5000 BTU
  • Left Rear Power: 10500 BTU
  • Right Front Power: 15000 BTU
  • Right Rear Power: 9200 BTU

Dimensions
  • Depth: 21 1/2
  • Height: 7 3/8
  • Width: 29 15/16
  • Cutout Depth: 19 15/16
  • Cutout Width: 28 1/2

Style and Extras
  • Controls: Knobs
  • Digital Display: No
  • Downdraft Vent: No

  • Signature Features
  • Electronic Ignition and Flame-Sensing™ Re-ignition
  • 15,000 BTU Ultra-High Output Burner
  • Ceran® Glass-Ceramic Surface
  • Control Features
  • Cast Metal Knobs
  • Infinite Burner Control Settings
  • Cooking Surface Features
  • Convertible to LP
  • May Be Installed Over 30" Electric Single Oven
  • 10,500 BTU Burner
  • 5,000 BTU Ultra-Low Output Burner
  • 9,200 BTU Burner
  • 4 Fixed Sealed Burners
  • Exterior Design Features
  • Porcelain-on-Cast-Iron Continuous Grates



Burners



  • Ultra low 650 BTU simmer burner
  • Sealed burners are built directly into the surface
  • 15,000 BTU ultra-high output burner
  • Smart Port Burner Design
  • Sealed Burners: 4

Controls



  • Infinite Burner Control Settings

Exterior



  • Porcelain-on-cast-iron burner grates
  • Color-coordinated burner grates
  • Ceran® Glass-Ceramic Surface
  • Cast Metal Knobs

Flexibility



  • Continuous burner grate design

Installation



  • May be installed above Jenn-Air® 30" (76.2cm) electric single wall oven.
  • Convertible to LP Gas
  • Accepts Optional Wok Accessory: Model #A0142

Performance



  • Flame Sensing™ re-ignition
  • Electronic Ignition

Specifications



  • Approximate Shipping Weight: 64 lbs/29 kgs

Manufacturer's Warranty: 2 years

Canadian model: JGC9430BDB

Specs
Burner Detail
Burner Cap Type Die Cast Steel
Burner Type Sealed
Ignition Type Electronic
Left Front Brnr High LP (BTU) 4000
Left Front Brnr High Nat (BTU) 5000
Left Front Brnr Low Nat (BTU) 650
Left Rear Brnr High Nat (BTU) 10500
Left Rear Burner High LP (BTU) 9100
Left Rear Burner Low Nat (BTU) 1300
Number of Burners 4
Right Front Brnr High LP (BTU) 15000
Right Front Brnr High Na (BTU) 15000
Right Front Brnr Low Nat (BTU) 1800
Right Rear Brnr High LP (BTU) 9100
Right Rear Brnr High Nat (BTU) 9200
Right Rear Brnr Low Nat (BTU) 13000
Cooking Surface Controls
Color Stainless
Location Split
Material Metal
Removable Knobs Yes
Type (Switch/Rotation Degrees) Knobs
Cooktop Specs
Burner Box Material Galvanized Steel
Cooktop Material Ceramic Glass
Cooktop Type Frameless
Gas Specifications
LP Gas Convertible Yes
Grate Detail
Grate Color Black
Grate Material Porcelain on Cast Iron
Grate Type Continuous
Number of Grates 2
Model
Fuel Type Natural Gas
