Five sealed burners, including a 17,000 BTU ultra-high output burner and a 5,000 BTU burner that reduces to ultra-low 650 BTUs, provide cooks the heat control needed for recipes requiring precise temperatures. The burners are built directly into the glass-ceramic surface, with no seams or burner bowls to trap spills, making this sleek cooktop as practical as it is beautiful.

Overview
This Jenn-Air® luxury gas cooktop offers power and precision along with a sleek glass-ceramic surface. It features five burners, including a 17,000 BTU ultra-high output burner. It also offers a lower-heat 5,000 BTU burner, which provides more gentle heat.

Specifications
Configuration and Overview

Cooktop Type: Standard
Size: 36
Fuel Type: Gas
Surface Material: Ceramic Glass
Burner or Element Style: Gas Burner
Number of Burners: 5
Installs Over Built-In Oven: Yes

Cooktop Features

Left Front Power: 9200 BTU
Left Rear Power: 5000 BTU
Center Front Power: 17000 BTU
Right Front Power: 12500 BTU
Right Rear Power: 5000 BTU

Dimensions

Depth: 21 1/2
Height: 7 3/8
Width: 35 3/8
Cutout Depth: 19 7/8
Cutout Width: 34 1/2

Style and Extras

Controls: Knobs
Digital Display: No
Downdraft Vent: No

Signature Features

Electronic Ignition and Flame-Sensing™ Re-ignition

17,000 BTU Ultra-High Output Burner

Ceran® Glass-Ceramic Surface

Control Features

Cast Metal Knobs

Infinite Burner Control Settings

Cooking Surface Features

Smart Port Burner Design

Convertible to LP

May Be Installed Over 30" Electric Single Oven

12,500 BTU Burner

5 Sealed Burners

9,200 BTU Burner

Two 5,000 BTU Ultra-Low Output Burners

Exterior Design Features

Porcelain-on-Cast-Iron Continuous Grates

Burners
- Two ultra low 650 BTU simmer burners
- Sealed burners are built directly into the surface
- Five sealed gas burners
- Ultra high output 17,000 BTU burner
- Smart Port Burner Design
Controls
- Infinite Burner Control Settings
Exterior
- Brushed stainless finish control knobs.
- Porcelain-on-cast-iron burner grates
- Color-coordinated burner grates
- Ceran® Glass-Ceramic Surface
- Cast Metal Knobs
Flexibility
- Continuous burner grate design
Installation
- Convertible to LP Gas
- May be installed above Jenn-Air® 30" (76.2cm) electric single wall oven.
- Accepts Optional Wok Accessory: Model # A0142
Performance
- Flame-Sensing™ re-ignition.
- Electronic Ignition
- SureFlame Ignition Protection
Specifications
- Approximate Shipping Weight: 72 lbs/32 kgs

Manufacturer's Warranty: 2 years

Canadian model: JGC9536BDB

Specs

Burner Detail
Burner Cap Finish	Porcelain
Centr Front Brnr High Na (BTU)	17000
Centr Rear Brnr High Nat (BTU)	15000
Centr Rear Brnr Low Nat (BTU)	17000
Ignition Type	Electronic
Left Front Brnr High LP (BTU)	9100
Left Front Brnr High Nat (BTU)	9200
Left Front Brnr Low Nat (BTU)	1300
Left Rear Brnr High Nat (BTU)	5000
Left Rear Burner High LP (BTU)	4000
Left Rear Burner Low Nat (BTU)	650
Number of Burners	5
Removable Burner Caps	Yes
Right Front Brnr High LP (BTU)	9100
Right Front Brnr High Na (BTU)	12500
Right Front Brnr Low Nat (BTU)	1300
Right Rear Brnr High LP (BTU)	4000
Right Rear Brnr High Nat (BTU)	5000
Right Rear Brnr Low Nat (BTU)	650
Cooking Surface Controls
Color	Stainless
Location	Split
Material	Metal
Removable Knobs	Yes
Type (Switch/Rotation Degrees)	Knobs
Cooktop Specs
Burner Box Material	Galvanized Steel
Cooktop Material	Ceramic Glass
Cooktop Type	Frameless
Gas Specifications
LP Gas Convertible	Yes
Grate Detail
Grate Color	Black
Grate Material	Porcelain on Cast Iron
Grate Type	Continuous
Number of Grates	3
Model
Fuel Type	Natural Gas

Manuals

>> View 2020 JennAir Parts & Accessories Guide <<

Dimension Guide (JGC9536BDB-dimension-guide-canada.pdf)

Installation Instruction (JGC9536BDB-installation-instruction-canada.pdf)

Use and Care (JGC9536BDB-use-and-care-canada.pdf)

Warranty (JGC9536BDB-warranty-canada.pdf)
