Thermador DWHD640JPR
Discontinued
Step up to Thermador DWHD661EPR for an extra $791
Step down to Thermador DWHD660EPR for an extra $221
BE0ZKM
Why Buy This at CAS?
Free In Home Delivery* - Dishwasher installation as low as $169
Haul Away Included
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
2 years manufacturer warranty included
Custom Advanced Installation Services - Dishwasher installation as low as $169
60 Day Returns
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $148.78 for 18 months
Ratings & Reviews
BE0ZKM
When will I get this?

Why Buy This at CAS?
Free In Home Delivery* - Dishwasher installation as low as $169
Haul Away Included
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
2 years manufacturer warranty included
Custom Advanced Installation Services - Dishwasher installation as low as $169
60 Day Returns
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $148.78 for 18 months
Description & Features

Thermador Topaz Series DWHD640JPR Fully Integrated Dishwasher with 14-Place Setting, 6 Wash Cycles, 4 Options, PowerBoost, Sens-A-Wash System, Chef's Tool Drawer and 44 dBA

The Thermador Dishwasher Collection of dishwashers delivers powerful performance with absolutely unparalleled flexibility. Our Dishwasher will compelement any Thermador kitchen.

  • Innovation
  • Blue PowerBeam operating indicator lets you know when the unit is running
  • Dosage Assist optimizes break down of detergent tablets
  • Performance
  • Crystal Protection System ensures perfect results for fine crystal
  • PowerBoost option increases temperature and pressure in the lower rack for the ultimate in heavy-duty cleaning
  • Sens-A-Wash ensures superior washing and drying guaranteed
  • Extra Dry option ensures perfectly dry dishes
  • Hand Wash allows you to delicately wash fine items and wine glasses
  • Accommodates 15 plate settings for your dinner parties
  • Powerfully Quiet - 44 dBA for peaceful kitchen experience
  • ENERGY STAR Qualified - uses only 269kWh/Yr
  • Extra-Tall-Item Sprinkler allows large items (22" high) to be washed
  • Design
  • Accepts custom panel with flush installation to match kitchen cabinetry
  • Stainless Steel Control Panel
  • Chef's Tool Drawer delivers added loading capacity for a range of small and large utensils
  • Sleek charcoal-grey racks with height-adjustment ability for added flexibility
  • Blue LED Display
  • 18/10 high-grade stainless steel interior offers long-lasting reliability, never rusts and resists nicks and chips

Design

  • Professional Handle and Fully Flush Stainless Steel Panel
  • Topaz 24"
  • 6 Programs and 4 options
  • DWHD640
  • Professional Handle
  • Stainless Steel Control Panel
  • Chef's Tool Drawer® delivers added loading capacity for a range of small and large utensils
  • Sleek charcoal-grey racks with height-adjustment ability for added flexibility
  • Blue LED Display
  • 18/10 high-grade stainless steel interior offers long-lasting reliability, never rusts and resists nicks and chips
  • Silver Painted Toe Kick
  • Accommodates 15 plate settings for your dinner parties

Quality

  • Blue PowerBeam® operating indicator lets you know when the unit is running
  • Dosage Assist optimizes break down of detergent tablets

Performance

  • Crystal Protection™ System ensures perfect results for fine crystal
  • PowerBoost® option increases temperature and pressure in the lower rack for the ultimate in heavy-duty cleaning
  • Sens-A-Wash® ensures superior washing and drying guaranteed
  • Extra Dry option ensures perfectly dry dishes
  • Hand Wash allows you to delicately wash fine items and wine glasses
  • Powerfully Quiet® - 44 dBA for peaceful kitchen experience
  • ENERGY STAR® Qualified - uses only 279kWh/Yr
  • Extra-Tall-Item™ Sprinkler allows large items (22" high) to be washed






Manufacturer's Warranty: 2 years

Canadian model: DWHD640JPR

Canadian UPC: 825225900122

EAN: 0825225900122

Specs
Technical Specifications
Width of the product (mm) 598 mm
Height of the product (mm) 865 mm
Installation Type Full-integrated
Number of place settings 14
List of programmes Auto US, Glass Care US, Power Scrub Plus US, Quick Wash US, Regular US, Rinse & Hold US
Cycle Options Extra dry, half load, Intensive Zone
Display Yes
Silence level (dBA) 44
3rd Rack Chef's Tool Drawer
Interior light No
Removable top No
Power cord length (cm) 175 cm
Length outlet hose (cm) 190 cm
Construction type
Control panel shape Frame MK
Color / Control Panel Stainless steel
Installation type Built-in
Panel ready Not possible
Drying system Inherent heat
Height of the product (mm) 865 mm
Concealed heating element Yes
Installation Type Full-integrated
Removable top No
Tub material Stainless steel
Water softener Yes
Width of the product (mm) 598 mm
Size and weight
Height of removable worktop (mm) 865 mm
Number of wash cycles 4
Adjustable plinth No
Net weight (kg) 43.700 kg
Programmes
List of programmes Auto US, Glass Care US, Power Scrub Plus US, Quick Wash US, Regular US, Rinse & Hold US
Program 1 Power Scrub Plus US
Program 2 Auto US
Program 3 Regular US
Program 4 Quick Wash US
Program 5 Glass Care US
Program 6 Rinse & Hold US
Programme duration, programme1 (min.) 110-135
Programme duration, programme2 (min.) 105-129
Programme duration, programme3 (min.) 95-119
Programme duration, programme4 (min.) 59
Programme duration, programme5 (min.) 70
Programme duration, programme6 (min.) 9
Reference programme Regular US
Temperature, programme 1 (°C) 66-71
Temperature, programme 2 (°C) 55-66
Temperature, programme 3 (°C) 50-55
Temperature, programme 4 (°C) 50
Temperature, programme 5 (°C) 50
Safety
Glass protection Yes
Surge-back protect. installed Yes
Leak protection system Aqua Stop
Consumption values
Glass protection Yes
Water consumption, programme 1 (l) 18.1-23.7
Water consumption, programme 2 (l) 13.1-24.9
Water consumption, programme 3 (l) 5.8-16.9
Water consumption, programme 4 (l) 14.1
Water consumption, programme 5 (l) 12.9
Water consumption, programme 6 (l) 4
Maximum temperature for water intake (°C) 60 °C
Connection
Watts (W) 1,300 W
Power cord length (cm) 175 cm
Current (A) 12 A
Length inlet hose (cm) 140 cm
Length outlet hose (cm) 190 cm
Plug type 120V-3 prong



Technical Specifications

Amps (A)

12

Frequency (Hz)

60

Approval certificates

CSA, UL

Plug type

120V-3 prong

Net weight (lbs)

102

Gross weight (lbs)

109

Length outlet hose (in)

55 1/8 ''

Length inlet hose (in)

55 1/8''

Tub material

Stainless steel

Tub type

TallTub

ADA compliant

No









Product Features

Leak protection system

24/7 Aqua Stop Plus

Optional accessories

SGZ1010UC, SGZ9091UC, SMZ5000, SMZ5002UC

Number of options

4

Start delay time max (h)

24

Concealed heating element

Yes

Five-level wash

Yes

Display

Yes

Status indicator

Time remaining indic. internal

Sanitized indicator light

Yes

Load sensor

Yes

Variable spray pressure

Yes

3rd Rack

3rd Rack 1.0

Silverware basket

Standard
