Manufacturer's Warranty: 1 year
Canadian model: ADW24PF
Similar to USA model: ADW24PF
Canadian UPC: 850044461431
Similar to USA UPC: 850044461431
EAN: 0850044461431
| Specification | Value |
|---|---|
| Brand | THOR Kitchen |
| Model | ADW24PF |
| Type | Built-in dishwasher |
| Style | Front-control, pocket handle |
| Color / Finish | Stainless steel |
| Capacity (Place Settings) | 12 place settings |
| Width | 23.62 inches |
| Depth (cabinet, excluding handle) | 22.68 inches |
| Depth with Door Open (approx.) | 46.3 inches |
| Height | 33.66 inches |
| Product Dimensions (W x D x H) | 23.62" x 22.68" x 33.66" |
| Cutout Width | 23.8 inches |
| Cutout Depth | 22.8 inches |
| Cutout Height | 34–35 inches |
| Door Opening Depth (90° from door to cabinet) | 27 inches |
| Net Weight | 70.86 lb |
| Gross Weight | 82.45 lb |
| Energy Star Certified | Yes |
| Sound Level | 52 dBA |
| Number of Wash Cycles | 7 (Auto / Heavy / Normal / Glass / ECO / Quick / Rinse) |
| Functional Options | 5 (including Heated Dry / Sanitize / Half-load, etc.) |
| Load Capacity (sets) | 12 sets |
| Water Consumption | 3.2 gallons per cycle (approx.) |
| Washing Performance | 80 Plus Certified |
| Tub Material | Stainless steel (hybrid tall tub with plastic base) |
| Number of Racks | 2 |
| Rack Material | Nylon coated |
| Adjustable Upper Rack | Yes |
| Fold-Down Tines | Yes |
| Cup Shelves | Yes |
| Stemware Holder | Yes |
| Cutlery / Silverware Basket | Three-piece silverware basket |
| Interior Finish | Stainless steel |
| Tall Tub | Yes (hybrid tall tub design) |
| Number of Spray Arms | 2 |
| Rinse Aid Dispenser | Yes |
| Water Filtration | Yes |
| Water Heating | Yes |
| Auto Detergent Dispenser | Yes |
| Interior Light | No |
| Control Type | Front control, touchpad / digital |
| Control Style | Full console |
| Display | Electronic display |
| Child Lock | Yes (control panel lock) |
| Delay Start | Yes (up to 24 hours) |
| Drying System | Forced hot air / heated dry, vented |
| High Temperature Wash | Yes |
| Sanitize Cycle / NSF Certification | Yes, NSF/ANSI 184 certified sanitization |
| Quick Wash Setting | Yes (Quick cycle) |
| China / Crystal Setting | Yes (Glass cycle) |
| Heavy Duty Wash | Yes (Heavy cycle) |
| Sensor / Smart Wash System | Yes (sensor clean / smart wash system) |
| Half Load Option | Yes (half-load function) |
| Delicate / Glass Wash | Yes |
| Rinse & Hold | Yes (Rinse cycle) |
| Steam Wash | No |
| Hard Food Disposer | No |
| Leak Protection | Yes |
| Wi-Fi / Smart Connectivity | No |
| Smart Home / App Compatible | No |
| Energy Star Rated | Yes |
| Annual Energy Use (approx.) | ~240 kWh/year (rated power usage) |
| Voltage | 120 V |
| Frequency | 60 Hz |
| Amperage | 7 A |
| Heater Power | 840 W (heater) |
| Motor Power | 50 W (motor) |
| Power Cord | Hard-wired |
| Water Feed Pressure | 20–120 psi (138–862 kPa) |
| Minimum / Suggested Inlet Water Temperature | 120 °F |
| Inlet Hose Length | Not specified by manufacturer |
| Outlet Hose Length | 52 inches |
| Installation | Side or top mounting |
| Handle Type | Pocket handle |
| Fingerprint Resistant | No |
| Country of Origin | China |
| UPC | 850044461431 |
| Warranty | 2-year limited (parts and labor) |
