Zephyr AEDM90ASX
Discontinued
ANYKQ9
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $117.28 for 18 months
Ratings & Reviews
ANYKQ9
When will I get this?

Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $117.28 for 18 months
Description & Features

Zephyr Ventilation gives dimensionality an Edge. This striking canopy design inspired by a wing's distinctive airfoil shape-perfectly befitting a ventilation device. The beveled stainless steel structure is seamlessly finished with integrated black glass controls, twin halogen lights and stylish stainless steel filters, lending this wall-mount range hood a decidedly professional air. Select poplar wood in a charcoal or wenge finish to complement your cabinetry, or choose the low-profile steel-only option for a perfect match with your kitchen's modern stainless look.

Wenge and Charcoal wood panels are optional.

•3 Speed Touch Glass Controls
•Decorative Mesh Filters
•CleanAir Function
•Delay Off
•2 Halogen Lights
•Tri-Level Lighting
•RF Remote Control
•6" or 8" Round Vertical Ducting


Manufacturer's Warranty: 1 year

Canadian model: AEDM90ASX

Specs
Models AED-M90ASX
Size 36"
CFM 290, 600, 1000
Recirculating yes
Ducting Vertical
Features
Controls: Memory Touch Glass
Speed Levels: 3
Delay-Off: Auto
CleanAir Function: Yes
Remote Control: Yes, RF
Lighting: Halogen, 20W x 2
Tri-Level Lighting: Yes
Filters: Decorative Mesh x 3
Recirculating: Optional
Duct Cover Extension: Optional
AC Input: 120V - 60Hz
AC Power - Hood Only: Max. 40W, 0.33 Amps
Performance (Blowers Sold Separately)
Internal Blower: 290 CFM, 3.2 Sones Max. (CBI290A)
Internal Blower: 600 CFM, 6.0 Sones Max. (CBI600A)
In-Line Blower: 1000 CFM, Sones NA (PBN1000A)
External Blower: 1000 CFM, Sones NA (CBE1000)
Duct Specifications
Vertical - Internal: 6"
Vertical - In-Line/External: 10" to 8"
Horizontal: N/A
Note: 10" round duct connects to external and in-line blower. Must transition from 10" to 8" before duct passes through ceiling. A 10" to 8" adapter is included with external and in-line blowers.
Dimensions
Overall Width: 35 3/8"
Overall Depth: 19 11/16"
Overall Height - Ducted: 28" Min. to 46" Max.
Overall Height - Recirculating: 33" Min. to 46" Max.
Height with Duct Cover Extension - Ducted: 44" Min. to 81" Max.
Height with Duct Cover Extension - Recirculating: 49" Min. to 81" Max.
Mounting Height from Cooking Surface: 24" Min. to 36" Max.
