Zephyr AK9028ASES
Out of Box / Floor Model Sale
Zephyr Ventilation 2024 Line Up Zephyr Ventilation 2024 Line Up
3J2A1P
Clearance (Floor Models Only)
MSRP Price
$989
Out of Box / Floor Model Sale
  • Vaughan Showroom ($525.40 CAD)
    27 Director Crt. Unit 1, Vaughan ON
from $525.40 CAD * In-store purchase only
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $48.28 for 18 months
Similar Colours and Options
AK9028AS-ES
AK9028AS-ES
3 Mounting
$899.00 CAD
3J2A1P
When will I get this?

Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $48.28 for 18 months
Description & Features
Vortex ENERGY STAR, One-Piece Liner, 28-3/8", SS, 290 CFM
  • Easy-to-use slide controls
  • Baffle filter for optimal air freshness
  • Fluorescent lighting
  • Maximum 3.5 Sones for minimal fan noise
  • Energy Star Qualified

Manufacturer's Warranty: 1 year

UPC: 646328003578

EAN: 0646328003578

Specs
Brand Zephyr
Manufacturer Zephyr
Category Range Hood
Sub-Category Insert
Vent Type Ducted
UPC 646328003578
GTIN 00646328003578
Country of Origin Taiwan
Model Group AK90-ES
Model Name Vortex Insert ENERGY STAR®
Collection Core Collection
Blower Included Yes
Internal Blower 1 CFM 290
Internal Blower 1 Min. Sones 1.3
Internal Blower 1 Max Sones 3.5
Minimum CFM 170
Installation Type Insert
Installation Type Insert
For Outdoor Use No
Color Stainless Steel
Controls Type Mechanical Slide
Blower Speeds 3
Automatic Delay-Off No
Clean Air Function No
Lighting Type Fluorescent
Lights Quantity 2
Watts Per Bulb 13
Lights Levels 1
Grease Filter Type Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number 50210016
Duct Discharge Vertical
Duct Size; Horizontal; IN N/A
Duct Size; Vertical; IN 6
Mounting Height Above Cooktop; IN 26 - 36
Voltage 120
Maximum Amperage 1.2
ADA Compliant No
Warranty Parts / Labor 3 / 1
Bluetooth Connected No
Wi-Fi Connected No
Remote Included No
Remote Optional No
Energy Star Certified Yes
Alexa & Google Home Compatible No
CEC Title 20 Compliant Yes
Primary Material Stainless Steel
Wattage 144
Certification UL
Nominal Width; IN 30
Net Width; IN 28.375
Net Depth; IN 17.5 - 20.5
Net Height; IN 12.3125
Weight; LBS 22.8
Ceiling Height Minimum 8 ft.
Ceiling Height Maximum 12 ft.
Shipping Length; IN 22.64
Shipping Width; IN 35.91
Shipping Height; IN 19.06
Shipping Weight; LBS 35.2
Shipping Method Small Parcel
Freight Class 150
Duct Type Vertical
Duct Type Vertical
Overview
Control Type:
Slide Control
Filter Type:
Baffle Filter
Lighting:
Fluorescent
Energy Star Qualified:
Yes
Air Flow:
290 CFM
Blower Type:
Internal
Number of Fan Speeds:
3
Ducting:
6" Round Vertical Ducting
Dimensions
Overall Width:
28 3/8"
Overall Depth:
17 1/2" - 20 1/2"
Insert Height:
12 3/8"
