Bertazzoni MAS486GDFSXT
Discontinued
AE5Z1Z
Why Buy This at CAS?
Free In Home Delivery*
Haul Away Included
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
2 years manufacturer warranty included
Custom Advanced Installation Services
60 Day Returns
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $623.23 for 18 months
Price Match & Beat Guarantee: We beat any competitor’s price!*
Ratings & Reviews
AE5Z1Z
When will I get this?

Why Buy This at CAS?
Free In Home Delivery*
Haul Away Included
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
2 years manufacturer warranty included
Custom Advanced Installation Services
60 Day Returns
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $623.23 for 18 months
Price Match & Beat Guarantee: We beat any competitor’s price!*
Description & Features

This super-wide range has a cooktop with six gas burners, including a dual-ring power burner, high-efficiency burner with separately controlled flames, and a stainless-steel electric griddle.

The main electric oven has nine functions, from convection, baking and roasting to warming and includes telescopic glide shelves. The pyrolytic oven linings requires no cleaning agents. High temperatures burn off fat and grease leaving a safe, easily disposed of residue. The useful auxiliary oven, without fan, has four modes. Quadruple-glass doors minimise heat loss.
Matching range hood and backsplash available.

All Bertazzoni appliances integrate seamlessly with each other and with the kitchen cabinetry and countertops.

Products and packaging are 99% recyclable.

Unique Features
  • 2 Year Parts and Labor Warranty is double the industry standard.
  • 25-1/8" Depth allows range to sit flush with cabinetry (as opposed to other pro brands).
  • All ranges include 4" stainless steel backguard (flat island trims optional).
  • All ranges include wok ring and simmer plate.
  • Convenient storage space below the oven for pots and pans (except where noted otherwise).
  • One piece, full-width inner glass oven door allows for easy cleaning.

    Cooking with The Surface Burners
  • 18,000 BTU dual control power burners.
  • All burners in brass.
  • High efficiency burners bring the flame closer to the pot to cook 30% faster.
  • Mechanical flame-out safety system with thermocouples guarantees shut-off.
  • One-piece worktop and sealed burners facilitate fast and easy cleaning.

    Cooking with The Gas Oven
  • Each range includes a telescopic glide shelf.
  • Full-width infrared broiler provides even heat over a large surface area.
  • Large capacity European convection oven is big enough for a 30 lb. turkey.
  • Low temperature settings include thermostat-controlled dehydration and fan-only defrosting.
  • Soft motion door hinges prevent slams, dropping and bounce-back.
  • Special multi-layer glass door ensures minimal heat loss and safe outer surface temps.

    Specifications
  • Height of all ranges is adjustable between 35-1/2" - 37-1/4".
  • LP models and conversions available.
  • LP models do not suffer the 20% loss in power seen in other brands.



Manufacturer's Warranty: 2 years

Canadian model: MAS486GDFSXT

EAN: 8034135389183

Specs
Worktop
Size: 48 in
Cooking zones: 7
Gas zones: 6
Griddle zones: electric
Worktop type: electric
gas
Worktop design: stainless steel squared
Worktop controls: knobs
Knobs: soft touch
Burner type: brass
Grates: cast iron
Continous grating: yes
Thermocouple safety device: yes
One-hand ignition: yes
Backguard: yes
Wok adapter: yes
Simmer ring: yes
Cooking zones
Dual wok: 750 BTU/h - 18 000.00 BTU/h
Rapid: 2500 BTU/h - 11 000.00 BTU/h (1)
Semi-rapid: 1500 BTU/h - 6500 BTU/h (3)
Auxiliary: 750 BTU/h - 3400 BTU/h (1)
Oven cavity
Oven configuration: double
Oven fuel: electric
Main oven type: electric pyrolytic
Main oven broiler type: electric
Main oven functions: bake
convection
convection bake
convection broiler
defrosting
dehydrate
large broiler
proofing
pyrolytic self clean
turbo
warming
Main oven volume: 3.40 ft
Main oven convection system: single
Auxiliary oven type: electric conventional
Auxiliary oven broiler type: electric
Auxiliary oven functions: bake
bottom bake
broiler
oven light
upper bake
Auxiliary oven volume: 1.70 ft
Oven controls: knobs
Inner oven door: quadruple
Removable inner glass: yes
Cooling fan: yes
Oven levels: 5
Sliding shelves: 1 standard
Wire-shelves: 2 heavy gauge chromed
Tray: 1 enamelled
Grill trivet for tray: yes
Oven lights: double diagonal
Bottom
Legs: stainless steel
Electrical requirements: 120/208 Vac - 60 Hz - 32 A
120/240 Vac - 60 Hz - 37 A
Worktop
Gas Zones: 6
Burners Type: Brass
Griddle: Electric
Design Worktop: Stainless Steel Squared
Worktop Control: Knobs
Knobs: Soft Touch
Pan Support: Cast Iron
Backguard: Yes
Thermocouple Safety Device: Yes
One Hand Ignition: Yes
Work Adapter: Yes
Simmer Ring: Yes
Cooking Zones
Dual Wok: 750 - 18,000 BTU/h
Rapid: 11,000 BTU/h
Semi-Rapid: 6,500 BTU/h
Auxiliary: 3,400 BTU/h
Simmer Rate: 750 BTU/h
Griddle: 1,100 Watts, Drip Tray
Oven Cavity
Main Oven: Electric Convection Self-Clean with Electric Broiler
Main Oven Volume: 3.4 Cu. Ft.
Auxiliary Oven: Electric with Electric Grill
Auxiliary Oven Volume: 1.7 Cu. Ft.
Temperature Gauge: No
Inner Oven Door: Quadruple Glass
Cooling Fan: Yes
Telescopic Glide Shelf: 1
Baking Tray: 1
Heavy Gauge Wire Shelves: 2
Grill Trivet For Tray: 1
Stainless Steel Legs: Yes
Height-Adjustable Legs: Yes
Main Oven Functions
Oven Light: No
Upper Bake: No
Bottom Bake / Gas Bake: No
Bake: Yes
Large Broiler: No
Broiler: Yes
Turbo / Gas Convection: Yes
Convection Bake: Yes
Convection Broiler: Yes
Convection: Yes
Defrost / Dehydrate: Yes
Warming / Sabbath Mode: Yes
Proofing: Yes
Self-Clean: Yes
Microwave: No
Convection / Microwave: No
Broiler / Microwave: No
Auxiliary Oven Functions
Oven Light: Yes
Upper Bake: Yes
Bottom Bake / Gas Bake: Yes
Bake: Yes
Broiler: Yes
Electrical Requirements
Voltage: 120/208 VAC - 120/240 VAC
Frequency: 60 Hz
Max Amp Usage: 32 Amps - 6,700 Watts, 37 Amps - 8,500 Watts
Certifications and Warranty
Certification: CSA
Warranty: 2 Years Parts and Labor
Dimensions
Overall Width: 48"
Overall Depth: 25 1/8"
Overall Depth Of Side Panel: 24"
Overall Height: 35 1/2" - 37 1/4"
