RA2236SQF Kobe Range Hood Canada Parts - Sale! Best Price, Reviews and Specs

Kobe SQ Series RA2236SQF Chimney-Style Wall Mount Range Hood with 700 CFM Internal Blower, 3 Speed Controls, LED Lights, QuietMode and Adjustable Duct Cover

With three speeds and a powerful squirrel cage motor, the Kobe RA2236SQF range hood offers something for all. The quiet mode speed runs at 280 CFM at a sound rating of 1.3 sones, making you wonder if it is even on! The high quality 18 gauge stainless steel construction and the low wattage LED lights are just another reason why Kobe is one of the best hood makers on the market.

Features:

35.75" Wide x 20.5" Deep x 4" High
700 CFM
6" Round Duct Size
Aluminum Mesh Filter
Uses Two 3 Watt LED Bulbs
Three Speed Options
Stainless Steel Construction
Meant to Be Used 20" to 35" Above Cooktop

Kobe range hoods is a leader in quiet kitchen ventilation. Kobe is recognized for providing top quality kitchen ventilation products in the United States, as well as Canada. Their goal is to design kitchen ventilation product with innovative styles, pioneering technology at an attractive price. They invite you to join them and play an important part in the innovation that Kobe creates for the kitchens of the future!

Manufacturer's Warranty: 2 years

Canadian model: RA2236SQF

Specs


MODEL / SIZE	RA2230SQF / 30" RA2236SQF / 36"	RA2230SQF / 30" RA2236SQF / 36"	RA2230SQF / 30" RA2236SQF / 36"
Design	18-Gauge Seamless Commercial Stainless Steel	18-Gauge Seamless Commercial Stainless Steel	18-Gauge Seamless Commercial Stainless Steel
Voltage	120V 60Hz	120V 60Hz	120V 60Hz
Motor Type	Compact Double Horizontal Squirrel Cage	Compact Double Horizontal Squirrel Cage	Compact Double Horizontal Squirrel Cage
Speed	QuietMode™	Low	High
Air Capacity (cfm)	280	480	700
Sone	1.3	2.8	4.8
Exhaust	Top 6" Round	Top 6" Round	Top 6" Round
Controls	Recessed Mechanical Push Button	Recessed Mechanical Push Button	Recessed Mechanical Push Button
LED Lights	12V 3W x 2	12V 3W x 2	12V 3W x 2
Hood Dimension (W x D x H)	(RA2230SQF): 29-3/4" x 20-1/2" x 4" (RA2236SQF): 35-3/4" x 20-1/2" x 4"	(RA2230SQF): 29-3/4" x 20-1/2" x 4" (RA2236SQF): 35-3/4" x 20-1/2" x 4"	(RA2230SQF): 29-3/4" x 20-1/2" x 4" (RA2236SQF): 35-3/4" x 20-1/2" x 4"
Weight (Lbs)		Net	Gross
Weight (Lbs)	RA2230SQF	38	51
Weight (Lbs)	RA2236SQF	42	58
Required Accessories (W x D x H)	Two-Piece Adjustable Duct Cover (RA22DC): 11-3/4" x 11-5/8" x (19-3/4" ~ 35-3/8")	Two-Piece Adjustable Duct Cover (RA22DC): 11-3/4" x 11-5/8" x (19-3/4" ~ 35-3/8")	Two-Piece Adjustable Duct Cover (RA22DC): 11-3/4" x 11-5/8" x (19-3/4" ~ 35-3/8")

Performance
Design:	18-Gauge Seamless Commercial Stainless Steel
Voltage:	120V; 15A; 60 Hz
Motor Type:	Compact Double Horizontal Squirrel Cage
Controls:	Recessed Mechanical Push Button
LED Lights:	12V 3W X 2
Duct Cover:	Included
Speed Modes
QuietMode:	280 CFM Air Capacity; 1.3 Sones
Low:	480 CFM Air Capacitty; 2.8 Sones
High:	700 CFM Air Capacity; 4.8 Sones
Dimensions and Weight
Product Width:	35 3/4"
Product Depth:	20 1/2"
Product Height:	4"
30" Gross Weight:	51 Lbs.
36" Gross Weight:	58 Lbs.

Manuals

Manual PDF (RA2236SQF-manual-canada.pdf)

Specification PDF (RA2236SQF-specification-1.pdf)
