Sharp

SMD3077ASC

• Microwave Drawer™ design – installs as a pull-out drawer for easy top‑down access, ideal for islands, peninsulas and open‑plan kitchens.

• Easy Touch Automatic Drawer System – Sharp’s exclusive motorized drawer mechanism opens with a gentle pull or touch of a button and closes smoothly to help prevent spills.

• AutoTouch™ System – one-touch automatic drawer opening and closing for convenient, hands‑free access when your hands are full.

• Sensor Cook® technology – automatically adjusts time and power using humidity sensors for more precise cooking and reheating.

• Microwave Drawer™ hidden control panel – concealed, tall control panel angled at 45° for a sleek built‑in look while remaining easy to see and use.

• Digital LCD display – clear, easy‑to‑read screen shows cooking times, power levels and function indicators at a glance.

• Virtual Carousel® interior – engineered cavity design circulates microwaves for even heating without a traditional turntable, simplifying loading and cleaning.

• 1.2 cu. ft. capacity – accommodates a 9" x 13" baking dish, large dinner plates, or tall mugs while fitting standard 30" cabinet openings.

• 950 watts of cooking power – delivers strong, consistent microwave performance for fast cooking and reheating.

• 11 power levels – fine‑tune power output for everything from gentle softening to full‑power cooking.

• 12 Sensor Cook™ settings – pre‑programmed options automatically cook common foods like vegetables, potatoes and entrées with minimal input.

• Sensor reheat and popcorn programs – dedicated sensor‑based settings for reheating leftovers and popping popcorn with optimal results.

• 2 preprogrammed reheat settings – one‑touch options for quickly reheating common meal portions.

• 6 automatic defrost settings – customized defrost programs for meats and other foods to thaw more evenly and safely.

• Melt settings – specialized cycles for gently melting items like butter, chocolate or cheese without scorching.

• Soften settings – softens foods such as ice cream or butter to a spreadable consistency.

• Warm function up to 30 minutes – keeps cooked dishes warm until serving without overcooking.

• Beverage setting – reheats coffee, tea or other drinks to a comfortable drinking temperature with one touch.

• 4 programmable cooking stages – allows multi‑step cooking (for example, defrost then cook then keep warm) to run automatically.

• Front‑mounted touch controls – controls positioned on the drawer front for ergonomic access without reaching overhead.

• Built‑in ready 30" width – designed to install below a wall oven, cooktop or counter without additional trim kits or venting in many applications.

• Location and counter‑space saving – frees up countertop space by moving the microwave into base cabinetry.

• Stainless steel finish – durable, contemporary exterior that coordinates with a wide range of kitchen appliances.

• Interior oven light – illuminates the cavity so you can monitor food without opening the drawer.

• Microwave timer and kitchen clock – built‑in timer and digital clock support everyday cooking and scheduling.

• Control lock (child lock) – disables the control panel to help prevent accidental or unsupervised use by children.

• Demonstration mode – allows showroom or in‑store display without activating full cooking power.

• Design flexibility – suitable for installation under counters, in islands, peninsulas, or under wall ovens and warming drawers.

• Safety compliance – meets FCC, DHHS and cUL safety standards for household microwave ovens.

• 120V, 60Hz operation – plugs into a standard household electrical circuit (14.5A, 1.67 kW).

• One‑year limited warranty plus 5‑year magnetron coverage – includes one year parts and labor with in‑home service, plus four additional years on the magnetron tube (parts only).

• Approx. 30" W x 15 7/8" H x 23" D – sized to fit most 30‑inch base cabinet cutouts with specified clearances.
