Zephyr AK9034BS
Zephyr Ventilation 2024 Line Up Zephyr Ventilation 2024 Line Up
3H0TNB
MSRP Price
$1,249
9% off
-$110
Online Price
$1,139
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $63.28 for 18 months
 Add to Cart
Call Local Showroom
Visit a Showroom
Ratings & Reviews
5
100%
recommend this
Read Reviews
(1 reviews)
Similar Colours and Options
AK9134BS
AK9134BS
300 CFM
$1,139.00 CAD
AK9234BS
AK9234BS
600 CFM
$1,779.00 CAD
AK9334BS
AK9334BS
1200 CFM
$2,859.00 CAD
AK9434BS
AK9434BS
700 CFM
$2,209.00 CAD
3H0TNB
Region Availability:
🛈 *7-20 Business Days
When will I get this?

 Add to Cart
Why Buy This at CAS?
Free In Home Delivery*
Cash-back
Up to 2% cash-back when paying by Visa® or Mastercard®!*
Custom Advanced Installation Services
Reserve & Pick Up
Interior Designer Discounts
Flexiti Financing as low as $63.28 for 18 months
Description & Features
Vortex, 36 in. SS, LED
  • LumiLight LED Lighting
  • LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours.
  • Hybrid Baffle Filters
  • Hybrid baffle filters utilize stainless steel baffles for an improved aesthetic and aluminum mesh for efficient filtration.
  • Powerful 390-CFM Blower
  • The range hood performance is measured in Cubic Feet per Minute (CFM). This is a measure of how much air can be removed from a given space in a single minute.
  • Mechanical Slide Controls
  • 3-speed mechanical slide controls move along a track to adjust the range hood blower and dual-level LED lighting.
  • Adjustable Depth
  • An adjustable-depth insert is designed to extend 3 inches to accommodate custom hood depths from 17-1/2 to 20-1/2 inches.
  • Dual-Level Lighting
  • The dual-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
  • Optional Ductless Recirculating Kit
  • Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.

Manufacturer's Warranty: 1 year

UPC: 646328009556

EAN: 0646328009556

Specs
Brand Zephyr
Manufacturer Zephyr
Category Range Hood
Sub-Category Insert
Vent Type Convertible
UPC 646328009556
GTIN 00646328009556
Country of Origin Taiwan
Model Group AK90-B
Model Name Vortex Insert
Collection Core Collection
Blower Included Yes
Internal Blower 1 CFM 390
Internal Blower 1 Min. Sones 1.4
Internal Blower 1 Max Sones 5
Minimum CFM 200
Installation Type Insert
Installation Type Insert
For Outdoor Use No
Color Stainless Steel
Controls Type Mechanical Slide
Blower Speeds 3
Automatic Delay-Off No
Clean Air Function No
Lighting Type LED
Lights Quantity 2
Watts Per Bulb 6
Lights Levels 2
Grease Filter Type Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number 50210030
Duct Discharge Vertical or Horizontal
Duct Size; Horizontal; IN 6
Duct Size; Vertical; IN 6
Mounting Height Above Cooktop; IN 24 - 34
Voltage 120
Maximum Amperage 4
ADA Compliant No
Warranty Parts / Labor 3 / 1
Compatible Appliances ZRC-9000, Z0F-C090
Bluetooth Connected No
Wi-Fi Connected No
Remote Included No
Remote Optional No
Energy Star Certified No
Alexa & Google Home Compatible No
CEC Title 20 Compliant Yes
CEC Title 24 Compliant Yes
Primary Material Stainless Steel
Wattage 480
Certification UL
Nominal Width; IN 36
Net Width; IN 34.375
Net Depth; IN 17.5
Net Height; IN 12.3125
Weight; LBS 34.6
Ceiling Height Minimum 8 ft.
Ceiling Height Maximum 12 ft.
Shipping Length; IN 39.37
Shipping Width; IN 22.64
Shipping Height; IN 19.09
Shipping Weight; LBS 39.5
Shipping Method Small Parcel
Freight Class 250
Certification # E127334
Clean Filter Alert No
Cutout Depth in. 10.5
Cutout Width in. 26.625
Duct Type Vertical
Duct Type Vertical
